3-48
SECTION 3
ELECTRICAL PARTS LIST
Numbering System of Resistor Numbering System of Capacitor
Example Example
KRD
Type
25
Wattage
F
Shape
J
Tolerance
101
Value
CCKR
Type
1H
Voltage
101
Value
K
Tolerance
B
Peculiarity
Resistor Type Wattage Tolerance
CRD: Carbon 20:1/5W F:= ±1%
CRG: Metal Oxide 25:1/4W J:= ±5%
50:1/2W K:= ±10%
1:1W
KRF: Metal Cement 2:2W
CRQ: Fusible 3:3W
Capacitor Type
Voltage
Tolerance
ECEA Type Other
HCB:Ceramic 0J:6.3V 1H:50V DC C: ±0.25pF
CCC:Ceramic 1A:10V 1:125V DC G: ±2%
CCK:Ceramic 1C:16V KC:400V AC J: ±5%
HCQI:Polyester 1E:25V 25:250V AC K: ±10%
KCQP:Polypropylene 1H:50V Z: +80%, –20%
KCQS:Polystyrol 1V:35V
KCEA:ELECT 2A:100V
KCF:SEMI
KCFE:FILM
Notes : • Part numbers are indicated for most mechanical parts.
Please use this part number for parts order.
• The unit of resistance is OHM (Ω)
K=1000 (Ω), M=1000 (KΩ)
• The unit of capacitance is MICROFARAD (µF)
P=10
-6
µF
RESISTORS AND CAPACITORS
MAIN B`D(CUP11395-1,2,3)
PCB1 CUP11395-1 PCB , MAIN L76
C271 HCEA1HH1R0T CAP , ELECT 1.0UF 50V
C272 , C273 CCCT1H220JC CAP , CERAMIC 22PF 50V J
C274 CCKT1H101KB CAP , CERAMIC 100PF 50 K
C275 HCEA1HHR47T CAP , ELECT 0.47UF 50V
C276 HCEA1AH471T CAP , ELECT 470UF 10V
C277 HCEA1EH470T CAP , ELECT 47UF 25V
C278 CCCT1H820JC CAP , CERAMIC 82PF 50V J
C279 CCCT1H560JC CAP , CERAMIC 56PF 50V J
C280 HCEA1HH1R0T CAP , ELECT 1.0UF 50V
C281 CCKT1H181KB CAP , CERAMIC 180PF 50V J
C282 HCQI1H682JZT CAP , MYLAR 6800PF 50 J
C283 HCEA1HH1R0T CAP , ELECT 1.0UF 50V
C284 CCKT1H223ZF CAP , CERAMIC 0.022UF 50V J
C285 , C286 CCCT1H270JC CAP , CERAMIC 27PF 50V J
C287 CCKT1H223ZF CAP , CERAMIC 0.022UF 50V Z
C288 HCEA1CH101T CAP , ELECT 100UF 16V
C289 CCCT1H820JC CAP , CERAMIC 82PF 50V J
C290 HCEA1AH471T CAP , ELECT 470UF 10V
C912 , C913 HCEA1EH101T CAP , ELECT 100UF 25V
C914 , C915 CCKT1H223ZF CAP , CERAMIC 0.022UF 50V Z
C916 , C917 HCEA1HH100T CAP , ELECT 10UF 50V
C918 , C919 HCEA1CH101T CAP , ELECT 100UF 16V
LOAD NO. PART NO. DESCRIPTION SPECIFICATION
