LOCATION OF CUSTOMER CONTROLS
POWER STANDBY/ON button
VFL Display
PHONES
BASS/TREBLE
Tone Controls
MASTER VOLUME
Control
BALANCE
Control
SOURCE SELECTOR
Control
AUDIO Signal jacks
VIDEO Signal jacks
PRE OUT jack
DIGITAL OUT jacks
SPEAKER terminals
Dolby Digital / DTS / PCM
DIGITAL IN jacks
S-VIDEO Signal jacks
FRONT PANEL
REAR PANEL
