NAD L76 - Page 31

3-50
CN41 KJP09GA98ZM WAFER MOLEX35336-0910
CN46 KJP07GA98ZM WAFER MOLEX35336-0710
CN51 , CN52 BJP06GA130ZK CONNECTOR (SOCKET) TAC-L06X-A3
CN61 , CN62 BJP06GA130ZK CONNECTOR (SOCKET) TAC-L06X-A3
CN71 , CN72 BJP06GA130ZK CONNECTOR (SOCKET) TAC-L06X-A3
CN75 BJP13GA98ZM CONNECTOR (SOCKET) TAC-L13X-A3
CN76 KJP03GA98ZM WAFER MOLEX35336-0310
CN78 KJP04GA01ZM WAFER MOLEX5276-04A
C901 , C902 KCET63VAH123N CAP , ELECT 12000UF/63V
C903 , C904 KCEA1VHS332E CAP , ELECT 3300UF/35V
C905 HCEA1CH332E CAP , ELECT 3300UF 16V
C922 HCEA1CH222E CAP , ELECT 2200UF 16V
IC27 HVIANAM2024V I.C , OSD LC74763-9730
RY79 HSL4A004ZU RELAY OSA-SS-212DM3
R908 , R909 CRG2ANJ470H RES , METAL OXIDE FILM 47 OHM 2W J
R912 CRG1ANJ470H RES , METAL OXIDE FILM 47 OHM 1W J
S799 KST1A010Z SW , TACT
X271 HOX17744D220F CRYSTAL
PCB2 CUP11395-2 PCB , TRANS
C906 , C907 KCFE1J473JBT CAP , FILM 0.047UF 63V J
C924 KCFE1J124JBT CAP , FILM 0.12UF 63V J
F903 , F904 KJCFC5S HOLDER , FUSE
R913 KRD25TJ103T RES , CARBON 10K OHM 1/4W J
D901 BVDGBJ1504 DIODE , BRIDGE GBJ1504
PCB3 CUP11395-3 PCB , TRANS
C908 ~ C911 KCFEJ124JBT CAP , FILM 0.12UF 63VJ
C951 HCEA1CH102E CAP , ELECT 1000UF 16UF
C953 HCEA1CH101T CAP , ELECT 100UF 16V
C954 HCEA1HH470T CAP , ELECT 47UF 50V
C955 HCEA1HH4R7T CAP , ELECT 4.7UF 50V
C952 , C956 HCEA1HH100T CAP , ELECT 10UF 50V
D902 ~ D909 KVD1N4003ST DIODE 1N4003
D913 , D951 KVD1N4003ST DIODE 1N4003
D952 HVDMTZJ6.2BT DIODE , ZENER 6.2V 1/2W
D953 KVD1N4003ST DIODE 1N4003
D954 HVDMTZJ33BT DIODE , ZENER 33V 1/2W
D956 HVDMTZJ6.2BT DIODE , ZENER 6.2V 1/2W
Q951 HVTKSC2316YT T.R KSC2316Y
Q952 KVTKSA1175YT T.R KSA1175Y
R951 CRD20TJ102T RES , CARBON 1K OHM 1/5W J
R952 , R953 CRD25TJ560T RES , CARBON 56 OHM 1/4W J
R954 CRD20TJ102T RES , CARBON 1K OHM 1/5W J
CN94 KJP09GA01ZM WAFER MOLEX 5267-09A
CN96 KJP06GA01ZM WAFER MOLEX 5267-06A
CN97 KJP03GA90ZM WAFER MOLEX 35313-0310
CN98 KJP08GB03ZM WAFER
R901 ~ R904 KRQ1CJR47 RES , FUSE
FRONT B'D
(CUP11551- 1,2,3,4,5,6,7)
PCB1 CUP11551-1 PCB , U-COM
C801 , C802 HCEA1HKS4R7T CAP , ELECT 4.7UF 50V
C803 , C804 HCBS1H101KBT CAP , CERAMIC 100PF 50V K
C805 , C806 HCEA1HKS4R7T CAP , ELECT 4.7UF 50V
LOAD NO. PART NO. DESCRIPTION SPECIFICATION
