NAD L76 - Page 34

3-53
R111 ~ R124 CRD20TJ104T RES , CARBON 100K OHM 1/5W J
R125 ~ R128 CRD20TJ471T RES , CARBON 470 OHM1/5W J
R129 ~ R131 CRD20TJ102T RES , CARBON 1K OHM 1/5W J
BN84 KJP12GB99ZM CONNECTOR
JK11 , JK12 CJJ4P039W JACK , IN/OUT
JK13 CJJ4R027W JACK , IN/OUT
PCB3 CUP11551-3 PCB , AUDIO BUFFER
C122 , C123 HCBS1H223ZFT CAP , CERAMIC 0.022UF 50V Z
C124 , C125 HCEA1VH101T CAP , ELECT 100UF 35V
C126 , C127 HCEA1HKS4R7T CAP , ELECT 4.7UF 50V
C128 , C129 HCBS1H223ZFT CAP , CERAMIC 0.022UF 50V Z
C130 , C131 HCEA1HKS4R7T CAP , ELECT 4.7UF 50V
IC12 BVIOPA2134UA IC , OP AMP
R132 ~ R135 CRD20TJ101T RES , CARBON 100 OHM 1/5W J
R136 ~ R141 CRD20TJ563T RES , CARBON 56K OHM 1/5W J
BN11 KJP06GB99ZM RES , CARBON MOLEX 35237-0610
BN12 KJP07GB99ZM CONNECTOR , HOUSING MOLEX 35237-0710
CN84 KJP12GA98ZM WAFER
PCB4 CUP11551-4 PCB , VIDEO INPUT
C201 CCCT1H470JC CAP , CERAMIC 47PF 50V J
C202 , C203 CCCT1H220JC CAP , CERAMIC 22PF 50V J
C204 CCCT1H470JC CAP , CERAMIC 47PF 50V J
C205 CCCT1H220JC CAP , CERAMIC 22PF 50V J
C206 ~ C208 HCEA1CKS100T CAP , ELECT 10UF 16V
C209 ~ C212 HCBS1H223ZFT CAP , CERAMIC 0.022UF 50V Z
C213 ~ C216 HCEA1AKS101T CAP , ELECT 100UF 10V
IC23 HVINJM2296M I.C , VIDEO SW
R201 ~ R205 CRD20TJ750T RES , CARBON 75 OHM 1/5W J
R206 , R207 CRD20TJ332T RES , CARBON 3.3K OHM 1/5W J
R208 , R209 CRD20TJ4R7T RES , CARBON 4.7 OHM 1/5W J
R210 ~ R213 CRD20TJ102T RES , CARBON 1K OHM 1/5W J
BN21 KJP09GB99ZM CONNECTOR MOLEX 35237-0910
JK21 CJJ4S003W JACK , VIDEO
JK22 CJJ4N044Z JACK , VIDEO
PCB5 CUP11551-5 PCB , S-VIDEO INPUT
C221 , C222 CCCT1H470JC CAP , CERAMIC 47PF 50V J
C223 ~ C226 CCCT1H220JC CAP , CERAMIC 22PF 50V J
C227 , C228 CCCT1H470JC CAP , CERAMIC 47PF 50V J
C229 , C230 CCCT1H220JC CAP , CERAMIC 22PF 50V J
C231 ~ C236 HCEA1CKS100T CAP , ELECT 10UF 16V
C237 ~ C242 HCBS1H223ZFT CAP , CERAMIC 0.022UF 50V J
C243 ~ C248 HCEA1AKS101T CAP , ELECT 100UF 10V
IC21 , IC22 HVINJM2296M I.C , VIDEO SW
R221 ~ R230 CRD20TJ750T RES , CARBON 75 OHM 1/5W J
R231 ~ R234 CRD20TJ332T RES , CARBON 3.3K OHM 1/5W J
R235 ~ R238 CRD20TJ4R7T RES , CARBON 4.7 OHM 1/5W J
R239 ~ R246 CRD20TJ102T RES , CARBON 1K OHM 1/5W J
BN22 KJP11GB99ZM CONNECTOR
JK23 HJJ9S001Z JACK , S-VIDEO JY-5041-040
JK24 HJJ9N001Z JACK , S-VIDEO JY-5036-040
SW21 KSS2D004Z SW , SLIDE JSS4208A
LOAD NO. PART NO. DESCRIPTION SPECIFICATION
