NAD L76 - Page 39

3-58
Q713 HVT2SA1695 T.R , POWER 2SA1695
ASS'Y 3 CMY1A166ZA HEAT SINK ASS'Y(R)
CMY1A166 SINK , HEAT(R)
Q513 , Q514 HVTKTC3114A T.R , (BIAS) KTC3114A
Q523 , Q524 HVT2SC4468 T.R , POWER 2SC4468
Q525 , Q526 HVT2SA1695 T.R , POWER 2SA1695
TH71 KRTP43T7D330B THERMAL SENSOR , POSISTOR P43T7D330BW1.5
POWER B'D
(CUP11431-1,2,3,4)
PCB1 CUP11431-1 PCB , SPEAKER B'D
C521 , C522 HCQI1H473JZT CAP , MYLAR 0.047UF 50V J
C523 , C524 HCQI1H562JZT CAP , MYLAR 5600PF 50V J
C525 , C526 HCQI1H473ZFT CAP , MYLAR 0.047UF 50V J
C621 , C622 HCQI1H473JZT CAP , MYLAR 0.047UF 50V J
C623 , C624 HCQI1H562JZT CAP , MYLAR 5600PF 50V J
C625 , C626 HCQI1H473JZT CAP , MYLAR 0.047UF 50V J
C757 HCQI1H473JZT CAP , MYLAR 0.047UF 50V J
C759 HCQI1H562JZT CAP , MYLAR 5600PF 50V J
C761 HCQI1H473JZT CAP , MYLAR 0.047UF 50V J
D507 HVD1SS133MT DIODE 1SS133
D607 HVD1SS133MT DIODE 1SS133
D759 HVD1SS133MT DIODE 1SS133
Q529 HVTKRC107MT T.R KRC107M
Q629 HVTKRC107MT T.R KRC107M
Q760 HVTKRC107MT T.R KRC107M
R573 , R574 CRD25TJ470T RES , CARBON 47 OHM 1/4W J
R579 CRD20TJ101T RES , CARBON 100 OHM 1/5W J
R580 , R581 CRD25TJ470T RES , CARBON 47 OHM 1/4W J
R673 , R674 CRD25TJ470T RES , CARBON 47 OHM 1/4W J
R677 CRD20TJ101T RES , CARBON 100 OHM 1/5W J
R678 , R679 CRD25TJ470T RES , CARBON 47 OHM 1/4W J
R770 , R771 KRD25TJ470T RES , CARBON 47 OHM 1/4W J
R773 CRD20TJ101T RES , CARBON 100 OHM 1/5W J
BN75 BJP13GB131ZK CONNECTOR(PLUG) TAC-L13P-B3
BN76 KJP03GB99ZM CONNECTOR MOLEX 35237-0310
JK51 CJJ5Q007Z TERMINAL , SP(RRRR/BBBB)
JK61 CJJ5N005Z TERMINAL , SP(R/B)
L501 , L502 CLEYK0R5KAK COIL , SPEAKER 0.5UH K
L601 , L602 CLEYK0R5KAK COIL , SPEAKER 0.5UH K
L701 CLEYK0R5KAK COIL , SPEAKER 0.5UH K
RY51 , RY61 HSL4A010ZU RELAY OSA-SS-212DM5
RY71 HSL1A008ZE RELAY SDT-S-112DMR
R575 , R576 CRG1ANJ100H RES , METAL OXIDE FILM 10 OHM 1W J
R577 , R578 CRG1ANJ331H RES , METAL OXIDE FILM 330 OHM 1W J
R675 , R676 CRG1ANJ100H RES , METAL OXIDE FILM 10 OHM 1W J
R772 CRG1ANJ100H RES , METAL OXIDE FILM 10 OHM 1W J
PCB2 CUP11431-2 PCB , AC OUTLET
D991 HVD1SS133MT DIODE 1SS133
F901 KJCFC5S HOLDER , FUSE
Q991 HVTKRC107MT T.R KRC107M
CN91 KJP02KA060ZY WAFER 7.92MM (YUNHO)
CN92 , CN93 KJP02GA89ZM WAFER MOLEX 35328-02
CN95 KJP03GA01ZM WAFER MOLEX 5267-03A
LOAD NO. PART NO. DESCRIPTION SPECIFICATION
