NAD M25 C - Page 29

DESIGNATOR DESCRIPTION PART TYPE PART NUMBER FOOTPRINT
C151
ALU Electrolytic
Capacitor
1uF/50V, 20%, 105
06-10951-03 CPCYL/D.200/LS.200/.031
C152 Polyester capacitor 1nF, 5%, 63V 25-10261-00 RAD/.300X.150/LS.200/.031
C153 Ceramic Capacitor 470pF, 10%, 1KV 05-47113-00 CPAX/.200X.100/.038
C154
ALU Electrolytic
Capacitor
10uF/100V, 20%, 105
06-10012-01 CPCYL1/D.300/LS.200/.031
C155
ALU Electrolytic
Capacitor
10uF/100V, 20%, 105
06-10012-01 CPCYL1/D.300/LS.200/.031
C156 Polyester capacitor 100nF, 10%, 63V 25-10461-00 RAD/.300X.150/LS.200/.035
C157
ALU Electrolytic
Capacitor
10uF/50V, 20%, 105
06-10051-01 CPCYL1/D.200/LS.200/.031
C158
ALU Electrolytic
Capacitor
10uF/50V, 20%, 105
06-10051-01 CPCYL1/D.200/LS.200/.031
C159 Polyester capacitor 1nF, 5%, 63V 25-10261-00 RAD/.300X.150/LS.200/.031
C160 Polyester capacitor 47nF, 5%, 63V 25-47361-01 RAD/.300X.150/LS.200/.034
C161 Polyester capacitor 47nF, 5%, 63V 25-47361-01 RAD/.300X.150/LS.200/.034
C1G1
Ceramic Capacitor
SMD
100nF, 10%, 50V 26-10451-11 SM/C_0805
CNI3 Ceramic Capacitor 15pF, 10%, 1KV 05-15013-00 CPAX/.200X.100/.032
CNI4 Ceramic Capacitor 22pF, 10%, 1KV 05-22013-00 CPAX/.200X.100/.032
CNI5 Ceramic Capacitor 22pF, 10%, 1KV 05-22013-00 CPAX/.200X.100/.032
CNI6 Polyester capacitor 100nF, 5%, 250V 25-10422-01 RAD/.300X.150/LS.200/.034
CNI7 Polyester capacitor 100nF, 5%, 250V 25-10422-01 RAD/.300X.150/LS.200/.034
CNI8 Ceramic Capacitor 47pF, 10%, 1KV 05-47013-00 CPAX/.200X.100/.031
CNI9 Ceramic Capacitor 47pF, 10%, 1KV 05-47013-00 CPAX/.200X.100/.031
L101 Inductor 0.7uH, horizontal type 08-01079-01 RAD/.850X.450/LS.700/.059
RL101 Relay JQX-115F/024/1HS1 12-03101-03 RELAY_1
RV101 POT 5K, RK09K1110482-5KA 09-01502-00 VPOT1
RV102 SEMI POT 300Ω, vertical type 09-02301-01 VRES17
RV103 SEMI POT 500Ω, vertical type 09-02501-02 VRES17
RV104 SEMI POT 100K, vertical type 09-02104-01 VRES17
F101 Fuse T6.3AL/250V 20-12632-00 5X20
F102 Fuse T6.3AL/250V 20-12632-00 5X20
W101 Jumper 5mm 21-06500-00 5mm
BUS101 Bus-Bar 69-010001-0
G1G1 Ground Solder Tap GND-8 32-28042-00
P101A Connector 9PIN 13-13909-00
P102A Connector 9PIN 13-13909-00
P103A Connector 6PIN2.54 90deg 13-12506-02
J101
Single RCA
Assemblage
White 17-01001-12 RCA_1A
R111 Test Pin 1PIN 13-10001-00
J103
Hs New Binding
PostRed
17-03001-03
J104
Hs New Binding
PostWhite
17-03001-04
D201 Switch Diode 1N4148 33-44148-02 DAX/.300X.080/.031
D202 Switch Diode 1N4148 33-44148-02 DAX/.300X.080/.031
D203 Switch Diode 1N4148 33-44148-02 DAX/.300X.080/.031
D204 Switch Diode 1N4148 33-44148-02 DAX/.300X.080/.031
D205 Switch Diode 1N4148 33-44148-02 DAX/.300X.080/.031
D206 Rectify Diode 1N4007 33-24007-02
INDUCTOR
RELAY
POT
FUSE
JUMPER
CONNECTOR
P/N 01-52502-00 PCB2 BOARD (POWER SUPPLY)
DIODE
ELECTRICAL PARTS LIST
- 29 -
