NAD M25 C - Exploded View Parts List

REF.NO PART NO. DESCRIPTION Qty. REF.NO PART NO. DESCRIPTION Qty.
A001 70-046001-0 Main Heatsink 7 F007 11-01101-20 SWITCH 1
A002 01-52510-10 AMP MODULE PCB Boards(AH) 7 F008 01-52503-00 PROTECT&SOFTCLIPPING LED BOARD1
01-52510-20 AMP MODULE PCB Boards(C) 7 F009 75-062001-0 Sleeve 2
A003 67-046011-1 Terminal Bracket 7
A004 17-01001-12 Single RCA Assemblage 7 R001 67-046005-2 Rear Panel(C) 1
A005 73-010001-0 Rotate Knob 7 67-046015-2 Rear Panel(AH) 1
A006 17-03001-03 Hs New Binding PostRed 7 R002 17-07003-01 AC Inlets 1
A007 17-03001-04 Hs New Binding PostWhite 7 R003 20-20000-03 Fuse Holder 1
A008 66-005009-0 TR CLAMPER 28 R004 71-003001-0 Grd. Post Bolt 1
A009 19-05005-00 Ferrite Bead 28 R005 71-003002-0 Grd. Post Cap 1
A010 69-046001-0 Bus-Bar 14 R006 66-010010-0 Bracket6 2
R007 01-52504-00 Trigger PCB Board 1
TR01 67-046013-1 Transformer Bracket 1
TR02 66-010004-0 Metal Disc 1 T001 67-046006-0 Top Cover 1
TR03 18-52513-00 Transformer(TOROID) 1 T002 76-046001-0 Screw Washer 8
TR04 94-046004-0 Transformer lable 1
TR05 75-010003-0 Insalation Cell 1 S001 61-223506-1 Hex Machine Screw 14
S002 61-023506-1 Machine Screw 35
C001 67-046004-1 Chassis 1 S003 61-373506-0 Machine Screw 7
C002 67-046007-0 Connector Bracket 1 S004 61-013206-0 Bolt 28
C003 67-046008-0 Front Troffer Bracket 1 S005 61-023208-0 Self Taping Screw 30
C004 67-046009-0 Rear Troffer Bracket 1 S006 61-023108-0 Self Taping Screw 59
C005 01-52506-00 Connection PCB Board 1 S007 61-023106-0 Self Taping Screw 76
C006 35-01212-00 FAN 3 S008 61-223514-0 Machine screw 28
C007 68-010003-0 Fan Cover 3 S009 64-110120-1 Bolt 1
C008 83-048010-0 Foot Assy 4 S010 63-011020-3 Washer 1
C009 79-046001-0 Shock Absorber Washer 24 S011 63-021030-0 Spring Washer 1
C010 79-046002-0 Shock Absorber Pad 12 S012 62-011002-1 Nut 1
C011 65-046001-0 Fan Pillar 12 S013 61-024108-0 Self Taping Screw 14
C012 85-001001-0 Space Support 2 S014 61-083509-6 Machine Screw 12
C013 67-046010-0 Power PCB Bracket 2 S015 61-084106-0 Self Taping Screw 1
C014 01-52502-00 Power Supply PCB Board 1 S016 63-030410-0 Serrated Lock Washer 2
C015 75-010001-0 Capacitor Holder 1 S017 61-063106-0 Self Taping Screw 25
C016 01-52505-10 Standby PCB Board(AH) 1 S018 63-010408-0 Washer 12
01-52505-20 Standby PCB Board(C) 1 S019 61-023206-0 Self Taping Screw 5
C017 01-52510-10 AH Version AMP Module 7 S020 61-224512-1 Hex Screws 9
01-52510-20 C Version AMP Module 7 S021 61-063108-5 Self Taping Screw 2
S022 61-224508-1 Hex Screws 4
S023 61-024208-0 Self Taping Screw 8
F001 70-046002-2 M25 Fascia 1 1 S024 61-084208-0 Self Taping Screw 1
F002 70-046003-0 M25 Fascia 2 1 S025 61-073208-0 Self Taping Screws 2
F003 67-046003-0 Subfascia 1 S026 63-010408-2 Washer 1
F004 67-046014-0 Panel Connect Bracket 2 S027 62-010402-1 Nut 1
F005 76-008001-0 LED Lens 9 S028 61-246508-0 M6X8 Hex Screw 8
F006 70-046004-0 Power Button 1 S029 63-030304-0 Serrated Lock Washer 8
-45-
EXPLODED VIEW PARTS LIST
