REF.NO PART NO. DESCRIPTION Qty.
1 88-046002-0 Shipping Carton Box 1
2 88-046001-0 Gift Carton Box 1
3 89-046001-1 M25 Botton Polyfoam 1
4 00-52500-20 M25 Unit 1
5 87-046002-0 Non-woven Cloth bag 1
6 90-010003-0 polyfbag 1
89-046002-0 M25 Top Polyfoam 1
8 88-043003-0 M15Accessories Box 1
9 30-45250-00 Instruction Manual 1
10 88-043004-0 M15Box Sheet 1
11 15-10230-20 AC Cord 1
7
PACKING DIAGRAM
