NAD M25 C - Electrical Parts List

DESIGNATOR DESCRIPTION PART TYPE PART NUMBER FOOTPRINT
D100 Switch Diode 1N4148 33-44148-02 DAX/.300X.080/.031
D101 Switch Diode 1N4148 33-44148-02 DAX/.300X.080/.031
D102 Switch Diode 1N4148 33-44148-02 DAX/.300X.080/.031
D103 Switch Diode 1N4148 33-44148-02 DAX/.300X.080/.031
D104 Switch Diode 1N4148 33-44148-02 DAX/.300X.080/.031
D105 Switch Diode 1N4148 33-44148-02 DAX/.300X.080/.031
D106 Switch Diode 1N4148 33-44148-02 DAX/.300X.080/.031
D107 LED φ3, Green 33-50350-00 DYL/D.200/LS.100/.039
D108 Switch Diode 1N4148 33-44148-02 DAX/.300X.080/.031
D109 LED φ3, Green 33-50350-00 DYL/D.200/LS.100/.039
D110 Switch Diode BAV21 33-40021-03 DAX/.300X.080/.031
D111 Switch Diode 1N4148 33-44148-02 DAX/.300X.080/.031
D112 Switch Diode 1N4148 33-44148-02 DAX/.300X.080/.031
D113 Switch Diode 1N4148 33-44148-02 DAX/.300X.080/.031
D114 Switch Diode 1N4148 33-44148-02 DAX/.300X.080/.031
D115 Switch Diode BAV21 33-40021-03 DAX/.300X.080/.031
D116 Switch Diode 1N4148 33-44148-02 DAX/.300X.080/.031
D117 Switch Diode 1N4148 33-44148-02 DAX/.300X.080/.031
D119 Switch Diode 1N4148 33-44148-02 DAX/.300X.080/.031
D120 Switch Diode 1N4148 33-44148-02 DAX/.300X.080/.031
D121 Switch Diode 1N4148 33-44148-02 DAX/.300X.080/.031
D122 Switch Diode 1N4148 33-44148-02 DAX/.300X.080/.031
D123 Switch Diode 1N4148 33-44148-02 DAX/.300X.080/.031
D124 Switch Diode 1N4148 33-44148-02 DAX/.300X.080/.031
D126 Switch Diode 1N4148 33-44148-02 DAX/.300X.080/.031
D127 Switch Diode 1N4148 33-44148-02 DAX/.300X.080/.031
D128 Switch Diode 1N4148 33-44148-02 DAX/.300X.080/.031
D129 Switch Diode BAV21 33-40021-03 DAX/.300X.080/.031
D130 Zener Diode 6.8V, 1/2W 33-16809-02 DAX/.300X.080/.031
D131 Zener Diode 4.7V, 1/2W 33-14709-01 DAX/.300X.080/.031
D132 Switch Diode BAV21 33-40021-03 DAX/.300X.080/.031
D133 Switch Diode 1N4148 33-44148-02 DAX/.300X.080/.031
D134 Switch Diode 1N4148 33-44148-02 DAX/.300X.080/.031
D135 Recti Diode 1N5404 33-25404-01 DAX/.600X.200/.059
D136 Switch Diode BAV21 33-40021-03 DAX/.300X.080/.031
D137 Switch Diode 1N4148 33-44148-02 DAX/.300X.080/.031
D138 Switch Diode BAV21 33-40021-03 DAX/.300X.080/.031
D139 Switch Diode 1N4148 33-44148-02 DAX/.300X.080/.031
D140 Switch Diode BAV21 33-40021-03 DAX/.300X.080/.031
Q100 Transistor 2SK170-BL 31-00170-00 TO92/100/DGS
Q101 Transistor 2SA970-GR 31-00970-00 TO92/100/ECB
Q102 Transistor 2SK170-BL 31-00170-00 TO92/100/DGS
Q103 Transistor 2SA970-GR 31-00970-00 TO92/100/ECB
Q104 Transistor 2SC2240-GR 31-02240-00 TO92/100/ECB
Q105 Transistor 2SC2240-GR 31-02240-00 TO92/100/ECB
Q106 Transistor 2SC2240-GR 31-02240-00 TO92/100/ECB
Q107 Transistor 2SC2240-GR 31-02240-00 TO92/100/ECB
Q108 Transistor 2SA970-GR 31-00970-00 TO92/100/ECB
Q109 Transistor 2SC2240-GR 31-02240-00 TO92/100/ECB
Q110 Transistor 2SC1815-GR 31-01815-00 TO92/100/ECB
Q111 Transistor 2SA1015-GR 31-01015-00 TO92/100/ECB
Q112 Transistor 2SK170-BL 31-00170-00 TO92/100/DGS
Q113 Transistor 2SA970-GR 31-00970-00 TO92/100/ECB
Q114 Transistor 2SC2240-GR 31-02240-00 TO92/100/ECB
Q115 Transistor 2SC2240-GR 31-02240-00 TO92/100/ECB
Q116 Transistor 2SC1815-GR 31-01815-00 TO92/100/ECB
Q117 Transistor 2SC1815-GR 31-01815-00 TO92/100/ECB
Q118 Transistor 2SA1015-GR 31-01015-00 TO92/100/ECB
DIODE
TRANSISTOR
AH P/N
 01-52501-10 C/BC P/N  01-52501-20 PCB1 BOARD (AMP)
ELECTRICAL PARTS LIST
- 24 -
