NAD M25 C - Page 25

DESIGNATOR DESCRIPTION PART TYPE PART NUMBER FOOTPRINT
Q119 Transistor 2SA1015-GR 31-01015-00 TO92/100/ECB
Q120 Transistor 2SA970-GR 31-00970-00 TO92/100/ECB
Q121 Transistor 2SA970-GR 31-00970-00 TO92/100/ECB
Q122 Transistor 2SA970-GR 31-00970-00 TO92/100/ECB
Q123 Transistor 2SA1360-O 31-01360-00 TO126/90/ECB
Q124 Transistor 2SC3423-O 31-03423-00 TO126/90/ECB
Q125 Transistor 2SC2240-GR 31-02240-00 TO92/100/ECB
Q126 Transistor 2SC3423-O 31-03423-00 TO126/90/ECB
Q127 Transistor MPSA92 31-00092-00 TO92/100/EBC
Q128 Transistor MJE340 31-00340-01 TO126/90/ECB
Q129 Transistor MJE350 31-00350-01 TO126/90/ECB
Q130 Transistor 2SC4793 31-04793-00 TO220AB/215/SURFACE/BCE
Q131 Transistor 2SA1837 31-01837-00 TO220AB/215/SURFACE/BCE
Q132 Power Transistor 2SC5200-O 31-05200-00 TO264/215/SURFACE/BCE
Q133 Power Transistor 2SA1943-O 31-01943-00 TO264/215/SURFACE/BCE
Q134 Power Transistor 2SC5200-O 31-05200-00 TO264/215/SURFACE/BCE
Q135 Power Transistor 2SA1943-O 31-01943-00 TO264/215/SURFACE/BCE
Q137 Transistor MPSA92 31-00092-00 TO92/100/EBC
Q138 Transistor MPSA42 31-00042-00 TO92/100/EBC
Q139 Transistor MPSA92 31-00092-00 TO92/100/EBC
Q140 Transistor MPSA42 31-00042-00 TO92/100/EBC
Q141 Transistor MPSA92 31-00092-00 TO92/100/EBC
Q142 Transistor 2N4403 31-04403-00 TO92/100/EBC
Q143 Transistor MPSA92 31-00092-00 TO92/100/EBC
Q144 Transistor MPSA92 31-00092-00 TO92/100/EBC
Q145 Transistor 2SC4793 31-04793-00 TO220AB/215/SURFACE/BCE
Q146 Transistor MPSA42 31-00042-00 TO92/100/EBC
Q147 Transistor MPSA92 31-00092-00 TO92/100/EBC
Q148 Transistor MPSA92 31-00092-00 TO92/100/EBC
Q149 Transistor MPSA42 31-00042-00 TO92/100/EBC
CB101
THERMAL CIRCUIT
BRAKE
67L090 03-67090-00 TO220AC/SURFACE
IC101 RAGULATOR NJM79M12FA 03-07912-20 TO220AB/SURFACE
IC102 RAGULATOR NJM78M12FA 03-07812-20 TO220AB/SURFACE
IC103 QUAD OP-AMP TL084BCD 03-00084-02 SOG.050/14/WG.244/L.375
IC104 DUAL OP-AMP TL082CP 03-00082-00 DIP.100/8/W.300/L.750
R100 Metal Film Resistor 470Ω, 1/6W, 5% 07-20471-00 AX/.200X.080/.031
R101 Metal Film Resistor 47Ω, 1/6W, 5% 07-20470-00 AX/.200X.080/.031
R102 Metal Film Resistor 2.2megΩ, 1/6W, 5% 07-20225-00 AX/.200X.080/.031
R103 Metal Film Resistor 470Ω, 1/6W, 5% 07-20471-00 AX/.200X.080/.031
R104 Metal Film Resistor 1KΩ, 1/6W, 5% 07-20102-00 AX/.200X.080/.031
R105 Metal Film Resistor 2.2megΩ, 1/6W, 5% 07-20225-00 AX/.200X.080/.031
R106 Metal Film Resistor 1KΩ, 1/6W, 5% 07-20102-00 AX/.200X.080/.031
R107 Metal Film Resistor 1KΩ, 1/6W, 1% 07-21001-00 AX/.200X.080/.031
R108 Metal Film Resistor 1KΩ, 1/6W, 1% 07-21001-00 AX/.200X.080/.031
R109 Metal Film Resistor 82Ω, 1/6W, 5% 07-20820-00 AX/.200X.080/.031
R110 Metal Film Resistor 1KΩ, 1/6W, 1% 07-21001-00 AX/.200X.080/.031
R111 Metal Film Resistor AOT, 1/6W, 1% 07-2****-00 AX/.200X.080/.031
R112 Metal Film Resistor 976Ω, 1/6W, 1% 07-29760-00 AX/.200X.080/.031
R113 Metal Film Resistor 82Ω, 1/6W, 5% 07-20820-00 AX/.200X.080/.031
R114 Metal Film Resistor 22KΩ, 1/6W, 5% 07-20223-00 AX/.200X.080/.031
R115 Metal Film Resistor 1KΩ, 1/6W, 5% 07-20102-00 AX/.200X.080/.031
R116 Metal Film Resistor 1K8Ω, 1/6W, 5% 07-20182-00 AX/.200X.080/.031
R117 Metal Film Resistor 82Ω, 1/6W, 5% 07-20820-00 AX/.200X.080/.031
R118 Metal Film Resistor 470Ω, 1/6W, 5% 07-20471-00 AX/.200X.080/.031
R119 Metal Film Resistor 2.2megΩ, 1/6W, 5% 07-20225-00 AX/.200X.080/.031
R120 Metal Film Resistor 1KΩ, 1/6W, 5% 07-20102-00 AX/.200X.080/.031
R121 Metal Film Resistor 1KΩ, 1/6W, 5% 07-20102-00 AX/.200X.080/.031
IC
THERMAL SWITCH
RESISTOR
ELECTRICAL PARTS LIST
-25-
