NAD M25 C - Page 26

DESIGNATOR DESCRIPTION PART TYPE PART NUMBER FOOTPRINT
R122 Metal Film Resistor 100Ω, 1/6W, 5% 07-20101-00 AX/.200X.080/.031
R123 Metal Film Resistor 100Ω, 1/6W, 5% 07-20101-00 AX/.200X.080/.031
R124 Metal Film Resistor 10KΩ, 1/6W, 5% 07-20103-00 AX/.200X.080/.031
R125 Metal Film Resistor 1KΩ, 1/6W, 5% 07-20102-00 AX/.200X.080/.031
R126 Metal Film Resistor 220Ω, 1/6W, 5% 07-20221-00 AX/.200X.080/.031
R127 Metal Film Resistor 4K7Ω, 1/6W, 5% 07-20472-00 AX/.200X.080/.031
R128 Metal Film Resistor 1megΩ, 1/6W, 5% 07-20105-00 AX/.200X.080/.031
R129 Metal Film Resistor 1megΩ, 1/6W, 5% 07-20105-00 AX/.200X.080/.031
R130 Metal Film Resistor 1KΩ, 1/6W, 5% 07-20102-00 AX/.200X.080/.031
R131 Metal Film Resistor 1KΩ, 1/6W, 5% 07-20102-00 AX/.200X.080/.031
R132 Metal Film Resistor 100Ω, 1/6W, 5% 07-20101-00 AX/.200X.080/.031
R133 Metal Film Resistor 100Ω, 1/6W, 5% 07-20101-00 AX/.200X.080/.031
R134 Metal Film Resistor 100Ω, 1/6W, 5% 07-20101-00 AX/.200X.080/.031
R135 Metal Film Resistor 180Ω, 1/6W, 5% 07-20181-00 AX/.200X.080/.031
R136 Metal Film Resistor 22KΩ, 1/6W, 5% 07-20223-00 AX/.200X.080/.031
R137 Metal Film Resistor 180Ω, 1/6W, 5% 07-20181-00 AX/.200X.080/.031
R138 Metal Film Resistor 22KΩ, 1/6W, 5% 07-20223-00 AX/.200X.080/.031
R139 Metal Film Resistor 100Ω, 1/6W, 5% 07-20101-00 AX/.200X.080/.031
R140 Metal Film Resistor 100Ω, 1/6W, 5% 07-20101-00 AX/.200X.080/.031
R141 Metal Film Resistor 1KΩ, 1/6W, 5% 07-20102-00 AX/.200X.080/.031
R142 Metal Film Resistor 1KΩ, 1/6W, 5% 07-20102-00 AX/.200X.080/.031
R143 Metal Film Resistor 100Ω, 1/6W, 5% 07-20101-00 AX/.200X.080/.031
R144 Metal Film Resistor 100Ω, 1/6W, 1% 07-21000-00 AX/.200X.080/.031
R145 Metal Film Resistor
2K78,1/6W,1%
07-22781-00 AX/.200X.080/.031
R146 Metal Film Resistor 100KΩ, 1/6W, 5% 07-20104-00 AX/.200X.080/.031
R147 Metal Film Resistor 47KΩ, 1/6W, 5% 07-20473-00 AX/.200X.080/.031
R148 Metal Film Resistor 100KΩ, 1/6W, 5% 07-20104-00 AX/.200X.080/.031
R149 Metal Film Resistor 47KΩ, 1/6W, 5% 07-20473-00 AX/.200X.080/.031
R150 Metal Film Resistor 3K9Ω, 1/6W, 5% 07-20392-00 AX/.200X.080/.031
R151 Metal Film Resistor 1KΩ, 1/6W, 5% 07-20102-00 AX/.200X.080/.031
R152 Metal Film Resistor 1.43KΩ, 1/6W, 1% 07-21431-00 AX/.200X.080/.031
R153 Metal Film Resistor 33Ω, 1/6W, 5% 07-20330-00 AX/.200X.080/.031
R154 Metal Film Resistor 10Ω, 1/4W, 5% 07-20100-10 AX/.400X.080/.031
R155 Metal Film Resistor 10Ω, 1/4W, 5% 07-20100-10 AX/.400X.080/.031
R156 FUSEABLE Resistor 1KΩ, 1/4W, 5% 07-50102-00 AX/.400X.080/.031
R157
Metal Oxide Film
Resistor
100Ω, 1/2W, 5% 07-30101-00 AX/.600X.125/.039
R158
Metal Oxide Film
Resistor
2.2Ω, 1W, 5% 07-30229-01 AX/.600X.125/.039
R159
Metal Oxide Film
Resistor
2.2Ω, 1W, 5% 07-30229-01 AX/.600X.125/.039
R160
Metal Oxide Film
Resistor
2.2Ω, 1W, 5% 07-30229-01 AX/.600X.125/.039
R161
Metal Oxide Film
Resistor
2.2Ω, 1W, 5% 07-30229-01 AX/.600X.125/.039
R162 Cement Resistor 0.22Ω, 5W, 5% 07-40228-05 AX/.1380X.375/.047
R163 Cement Resistor 0.22Ω, 5W, 5% 07-40228-05 AX/.1380X.375/.047
R164 Cement Resistor 0.22Ω, 5W, 5% 07-40228-05 AX/.1380X.375/.047
R165 Cement Resistor 0.22Ω, 5W, 5% 07-40228-05 AX/.1380X.375/.047
R168 Metal Film Resistor 22KΩ, 1/6W, 5% 07-20223-00 AX/.200X.080/.031
R169 Metal Film Resistor 4K7Ω, 1/6W, 5% 07-20472-00 AX/.200X.080/.031
R170 Metal Film Resistor 22KΩ, 1/6W, 5% 07-20223-00 AX/.200X.080/.031
R171 Metal Film Resistor 22KΩ, 1/6W, 5% 07-20223-00 AX/.200X.080/.031
R172 Metal Film Resistor 10KΩ, 1/6W, 5% 07-20103-00 AX/.200X.080/.031
R173 Metal Film Resistor 22KΩ, 1/6W, 5% 07-20223-00 AX/.200X.080/.031
R174 Metal Film Resistor 100KΩ, 1/6W, 5% 07-20104-00 AX/.200X.080/.031
R175 Metal Film Resistor 10KΩ, 1/6W, 5% 07-20103-00 AX/.200X.080/.031
R176 Metal Film Resistor 100KΩ, 1/6W, 5% 07-20104-00 AX/.200X.080/.031
R177
Metal Oxide Film
Resistor
3.3Ω, 1W, 5% 07-30339-10 AX/.800X.200/.037
R178
Metal Oxide Film
Resistor
2.7Ω, 2W, 5% 07-30279-02 AX/.800X.200/.037
ELECTRICAL PARTS LIST
-26-
