NAD M25 C - Page 27

DESIGNATOR DESCRIPTION PART TYPE PART NUMBER FOOTPRINT
R180 Metal Film Resistor 10KΩ, 1/6W, 5% 07-20103-00 AX/.200X.080/.031
R181 Metal Film Resistor 22KΩ, 1/6W, 5% 07-20223-00 AX/.200X.080/.031
R182 Metal Film Resistor 3K3Ω, 1/6W, 1% 07-23301-00 AX/.200X.080/.031
R183 Metal Film Resistor 220KΩ, 1/6W, 5% 07-20224-00 AX/.200X.080/.031
R184 Metal Film Resistor 20KΩ, 1/6W, 5% 07-20203-00 AX/.200X.080/.031
R185 Metal Film Resistor 20KΩ, 1/6W, 5% 07-20203-00 AX/.200X.080/.031
R186 Metal Film Resistor 1megΩ, 1/6W, 5% 07-20105-00 AX/.200X.080/.031
R187 Metal Film Resistor 10KΩ, 1/6W, 5% 07-20103-00 AX/.200X.080/.031
R188 Metal Film Resistor 51KΩ, 1/6W, 5% 07-20513-00 AX/.200X.080/.031
R189 Metal Film Resistor 510KΩ, 1/6W, 5% 07-20514-00 AX/.200X.080/.031
R190 Metal Film Resistor 20KΩ, 1/6W, 5% 07-20203-00 AX/.200X.080/.031
R191 Metal Film Resistor 20KΩ, 1/6W, 5% 07-20203-00 AX/.200X.080/.031
R192 Metal Film Resistor 2K21Ω, 1/6W, 1% 07-22211-00 AX/.200X.080/.031
R193 Metal Film Resistor 20KΩ, 1/6W, 5% 07-20203-00 AX/.200X.080/.031
R194 Metal Film Resistor 10KΩ, 1/6W, 5% 07-20103-00 AX/.200X.080/.031
R195 Metal Film Resistor 100KΩ, 1/6W, 5% 07-20104-00 AX/.200X.080/.031
R196
Metal Oxide Film
Resistor
100Ω, 1/2W, 5% 07-30101-00 AX/.600X.125/.039
R197 Metal Film Resistor 20KΩ, 1/6W, 5% 07-20203-00 AX/.200X.080/.031
R198 Metal Film Resistor 100KΩ, 1/6W, 5% 07-20104-00 AX/.200X.080/.031
R199 Metal Film Resistor 220KΩ, 1/6W, 5% 07-20224-00 AX/.200X.080/.031
R1A0 Metal Film Resistor 390KΩ, 1/6W, 5% 07-20394-00 AX/.200X.080/.031
R1A1 Metal Film Resistor 220KΩ, 1/6W, 5% 07-20224-00 AX/.200X.080/.031
R1A2 Metal Film Resistor 10KΩ, 1/6W, 5% 07-20103-00 AX/.200X.080/.031
R1A3 Metal Film Resistor 470kΩ, 1/6W, 5% 07-20474-00 AX/.200X.080/.031
R1A4 Metal Film Resistor 220KΩ, 1/6W, 5% 07-20224-00 AX/.200X.080/.031
R1A5 Metal Film Resistor 220KΩ, 1/6W, 5% 07-20224-00 AX/.200X.080/.031
R1A6 Metal Film Resistor 47KΩ, 1/6W, 5% 07-20473-00 AX/.200X.080/.031
R1A7 Cement Resistor 0.05Ω, 3W, 5% 07-40507-04 RAD/.525X.200/LS.315/.039
R1A8 Metal Film Resistor 100Ω, 1/6W, 5% 07-20101-00 AX/.200X.080/.031
R1A9 Metal Film Resistor 6K8Ω, 1/6W, 5% 07-20682-00 AX/.200X.080/.031
R1H3 Metal Film Resistor 10KΩ, 1/6W, 5% 07-20103-00 AX/.200X.080/.031
R1E0 Metal Film Resistor 470kΩ, 1/6W, 5% 07-20474-00 AX/.200X.080/.031
R1E1 Metal Film Resistor 3K3Ω, 1/6W, 1% 07-23301-00 AX/.200X.080/.031
R1E2 Metal Film Resistor 33KΩ, 1/6W, 1% 07-23302-00 AX/.200X.080/.031
R1E3 Metal Film Resistor 1K5Ω, 1/6W, 5% 07-20152-00 AX/.200X.080/.031
R1G1
Metal Oxide Film
Resistor
100Ω, 2W, 5% 07-30101-05 AX/.800X.200/.037
R1H1 Metal Film Resistor 100Ω, 1/6W, 5% 07-20101-00 AX/.200X.080/.031
R1H2 Metal Film Resistor 100Ω, 1/6W, 5% 07-20101-00 AX/.200X.080/.031
R1N1 Metal Film Resistor 220KΩ, 1/6W, 5% 07-20224-00 AX/.200X.080/.031
R1N2 Metal Film Resistor 33KΩ, 1/6W, 1% 07-23302-00 AX/.200X.080/.031
R1N3 Metal Film Resistor 33KΩ, 1/6W, 1% 07-23302-00 AX/.200X.080/.031
R1N4 Metal Film Resistor 220KΩ, 1/6W, 5% 07-20224-00 AX/.200X.080/.031
R1N5 Metal Film Resistor 220Ω, 1/6W, 5% 07-20221-00 AX/.200X.080/.031
R1N6 Metal Film Resistor 220Ω, 1/6W, 5% 07-20221-00 AX/.200X.080/.031
R1N7 Metal Film Resistor 2KΩ, 1/6W, 5% 07-20202-00 AX/.200X.080/.031
R1N8 Metal Film Resistor 2KΩ, 1/6W, 5% 07-20202-00 AX/.200X.080/.031
R1P1 Metal Film Resistor 2KΩ, 1/6W, 5% 07-20202-00 AX/.200X.080/.031
R1P2 Metal Film Resistor 2KΩ, 1/6W, 5% 07-20202-00 AX/.200X.080/.031
R1P3 Metal Film Resistor 100Ω, 1/6W, 5% 07-20101-00 AX/.200X.080/.031
R1P4 Metal Film Resistor 100Ω, 1/6W, 5% 07-20101-00 AX/.200X.080/.031
R1P5 Metal Film Resistor 2KΩ, 1/6W, 5% 07-20202-00 AX/.200X.080/.031
R1P6 Metal Film Resistor 2KΩ, 1/6W, 5% 07-20202-00 AX/.200X.080/.031
C100 Ceramic Capacitor 180pF, 10%, 1KV 05-18113-00 CPAX/.200X.100/.036
C101 Polyester capacitor 1nF, 5%, 63V 25-10261-00 RAD/.300X.150/LS.200/.031
C102 Ceramic Capacitor 22pF, 5%, 1KV 05-22013-02 CPAX/.200X.100/.032
C103 Ceramic Capacitor 180pF, 10%, 1KV 05-18113-00 CPAX/.200X.100/.036
C104 Polyester capacitor 1nF, 5%, 63V 25-10261-00 RAD/.300X.150/LS.200/.031
C105 Ceramic Capacitor 47pF, 5%, 1KV 05-47013-01 CPAX/.200X.100/.031
CAPACTIOR
ELECTRICAL PARTS LIST
-27-
