NAD M25 C - Page 32

DESIGNATOR DESCRIPTION PART TYPE PART NUMBER FOOTPRINT
R231 Metal Film Resistor 10KΩ, 1/6W, 5% 07-20103-00 AX/.200X.080/.031
R232 Metal Film Resistor 10KΩ, 1/6W, 5% 07-20103-00 AX/.200X.080/.031
R233
Metal Oxide Film
Resistor
10KΩ, 1/2W, 5% 07-30103-00 AX/.400X.100/.031
R234
Metal Oxide Film
Resistor
10KΩ, 1/2W, 5% 07-30103-00 AX/.400X.100/.031
R235 Metal Film Resistor 1KΩ, 1/6W, 5% 07-20102-00 AX/.200X.080/.031
R236 Metal Film Resistor 1KΩ, 1/6W, 5% 07-20102-00 AX/.200X.080/.031
R237 Metal Film Resistor 1KΩ, 1/6W, 5% 07-20102-00 AX/.200X.080/.031
R238
Metal Oxide Film
Resistor
47Ω, 1/2W, 5% 07-30470-00 AX/.400X.080/.031
R239 Metal Film Resistor 1KΩ, 1/6W, 5% 07-20102-00 AX/.200X.080/.031
R240
Metal Oxide Film
Resistor
47Ω, 1/2W, 5% 07-30470-00 AX/.400X.080/.031
R241 Metal Film Resistor 10KΩ, 1/6W, 5% 07-20103-00 AX/.200X.080/.031
R242
Metal Oxide Film
Resistor
10KΩ, 1/2W, 5% 07-30103-00 AX/.400X.100/.031
R243
Metal Oxide Film
Resistor
10KΩ, 1/2W, 5% 07-30103-00 AX/.400X.100/.031
R244 Metal Film Resistor 1KΩ, 1/6W, 5% 07-20102-00 AX/.200X.080/.031
R245 Metal Film Resistor 1KΩ, 1/6W, 5% 07-20102-00 AX/.200X.080/.031
R246 Metal Film Resistor 1KΩ, 1/6W, 5% 07-20102-00 AX/.200X.080/.031
R247
Metal Oxide Film
Resistor
47Ω, 1/2W, 5% 07-30470-00 AX/.400X.080/.031
R248 Metal Film Resistor 1KΩ, 1/6W, 5% 07-20102-00 AX/.200X.080/.031
R249
Metal Oxide Film
Resistor
47Ω, 1/2W, 5% 07-30470-00 AX/.400X.080/.031
R250 Metal Film Resistor 470Ω, 1/6W, 5% 07-20471-00 AX/.200X.080/.031
R251 Metal Film Resistor 1KΩ, 1/6W, 5% 07-20102-00 AX/.200X.080/.031
R252 Metal Film Resistor 100KΩ, 1/6W, 5% 07-20104-00 AX/.200X.080/.031
R253 Metal Film Resistor 1KΩ, 1/6W, 5% 07-20102-00 AX/.200X.080/.031
R254 Metal Film Resistor 470Ω, 1/6W, 5% 07-20471-00 AX/.200X.080/.031
R255 Metal Film Resistor 4K7Ω, 1/6W, 5% 07-20472-00 AX/.200X.080/.031
R256 Metal Film Resistor 1KΩ, 1/6W, 5% 07-20102-00 AX/.200X.080/.031
R257 Metal Film Resistor 10KΩ, 1/6W, 5% 07-20103-00 AX/.200X.080/.031
R258 Metal Film Resistor 10KΩ, 1/6W, 5% 07-20103-00 AX/.200X.080/.031
R259 Metal Film Resistor 100Ω, 1/6W, 5% 07-20101-00 AX/.200X.080/.031
R260 Metal Film Resistor 2KΩ, 1/6W, 5% 07-20202-00 AX/.200X.080/.031
R261 Metal Film Resistor 10KΩ, 1/6W, 1% 07-21002-00 AX/.200X.080/.031
R262 Metal Film Resistor 10KΩ, 1/6W, 1% 07-21002-00 AX/.200X.080/.031
R263 Metal Film Resistor 10KΩ, 1/6W, 1% 07-21002-00 AX/.200X.080/.031
R264 Metal Film Resistor 10KΩ, 1/6W, 1% 07-21002-00 AX/.200X.080/.031
R265 Metal Film Resistor 10KΩ, 1/6W, 1% 07-21002-00 AX/.200X.080/.031
R266 Metal Film Resistor 10KΩ, 1/6W, 1% 07-21002-00 AX/.200X.080/.031
R267 Metal Film Resistor 10KΩ, 1/6W, 1% 07-21002-00 AX/.200X.080/.031
R268 Metal Film Resistor 10KΩ, 1/6W, 1% 07-21002-00 AX/.200X.080/.031
R269 Metal Film Resistor 10KΩ, 1/6W, 1% 07-21002-00 AX/.200X.080/.031
R270 Metal Film Resistor 43KΩ, 1/6W, 1% 07-24302-00 AX/.200X.080/.031
R271 Metal Film Resistor 43KΩ, 1/6W, 1% 07-24302-00 AX/.200X.080/.031
R272 Metal Film Resistor 43KΩ, 1/6W, 1% 07-24302-00 AX/.200X.080/.031
R273 Metal Film Resistor 100Ω, 1/6W, 5% 07-20101-00 AX/.200X.080/.031
R274 Metal Film Resistor 100Ω, 1/6W, 5% 07-20101-00 AX/.200X.080/.031
R275 Metal Film Resistor 100Ω, 1/6W, 5% 07-20101-00 AX/.200X.080/.031
R276 Metal Film Resistor 3K3Ω, 1/6W, 5% 07-20332-00 AX/.200X.080/.031
R277 Metal Film Resistor 3K3Ω, 1/6W, 5% 07-20332-00 AX/.200X.080/.031
R278 Metal Film Resistor 3K3Ω, 1/6W, 5% 07-20332-00 AX/.200X.080/.031
R279 Metal Film Resistor 3K3Ω, 1/6W, 5% 07-20332-00 AX/.200X.080/.031
R280 Metal Film Resistor 10KΩ, 1/6W, 5% 07-20103-00 AX/.200X.080/.031
R281 Metal Film Resistor 10KΩ, 1/6W, 5% 07-20103-00 AX/.200X.080/.031
R282 Metal Film Resistor 10KΩ, 1/6W, 5% 07-20103-00 AX/.200X.080/.031
R283 Metal Film Resistor 10KΩ, 1/6W, 5% 07-20103-00 AX/.200X.080/.031
R284 Metal Film Resistor 10KΩ, 1/6W, 5% 07-20103-00 AX/.200X.080/.031
ELECTRICAL PARTS LIST
- 32 -
