NAD M25 C - Page 35

DESIGNATOR DESCRIPTION PART TYPE PART NUMBER FOOTPRINT
C255
ALU Electrolytic
Capacitor
2200uF/25V, 20%, 105
06-22221-04 CPCYL1/D.900/LS.350/.062
C256 Polyester capacitor 10nF, 10%, 100V 25-10312-01 RAD/.300X.150/LS.200/.035
C257 Polyester capacitor 100nF, 10%, 100V 25-10412-02 RAD/.300X.150/LS.200/.037
C258 Polyester capacitor 10nF, 10%, 100V 25-10312-01 RAD/.300X.150/LS.200/.035
C259
ALU Electrolytic
Capacitor
1uF/50V, 20%, 105
06-10951-10 CPCYL1/D.200/LS.200/.031
C260
ALU Electrolytic
Capacitor
1uF/50V, 20%, 105
06-10951-10 CPCYL1/D.200/LS.200/.031
C261
ALU Electrolytic
Capacitor
1uF/50V, 20%, 105
06-10951-10 CPCYL1/D.200/LS.200/.031
C262 Ceramic Capacitor 220pF, 10%, 1KV 05-22113-01 CPAX/.200X.100/.031
C263 Polyester capacitor 100nF, 10%, 100V 25-10412-02 RAD/.300X.150/LS.200/.037
C264
ALU Electrolytic
Capacitor
100uF/16V, 20%, 105
06-10111-07 CPCYL1/D.200/LS.200/.031
C265 Polyester capacitor 100nF, 10%, 100V 25-10412-02 RAD/.300X.150/LS.200/.037
C266 Polyester capacitor 100nF, 10%, 100V 25-10412-02 RAD/.300X.150/LS.200/.037
C267
ALU Electrolytic
Capacitor
10uF/50V, 20%, 105
06-10051-01 CPCYL1/D.200/LS.200/.031
C268
ALU Electrolytic
Capacitor
10uF/50V, 20%, 105
06-10051-01 CPCYL1/D.200/LS.200/.031
C269
ALU Electrolytic
Capacitor
10uF/50V, 20%, 105
06-10051-01 CPCYL1/D.200/LS.200/.031
C270
ALU Electrolytic
Capacitor
10uF/50V, 20%, 105
06-10051-01 CPCYL1/D.200/LS.200/.031
C271 Polyester capacitor 100nF, 10%, 100V 25-10412-02 RAD/.300X.150/LS.200/.037
C272 Polyester capacitor 100nF, 10%, 100V 25-10412-02 RAD/.300X.150/LS.200/.037
C273 Polyester capacitor 100nF, 10%, 100V 25-10412-02 RAD/.300X.150/LS.200/.037
C274 Polyester capacitor 100nF, 10%, 100V 25-10412-02 RAD/.300X.150/LS.200/.037
C275 Polyester capacitor 100nF, 10%, 100V 25-10412-02 RAD/.300X.150/LS.200/.037
C276
ALU Electrolytic
Capacitor
10uF/50V, 20%, 105
06-10051-01 CPCYL1/D.200/LS.200/.031
C277
ALU Electrolytic
Capacitor
10uF/50V, 20%, 105
06-10051-01 CPCYL1/D.200/LS.200/.031
RV201 SEMI POT 1K, vertical type 09-02102-02 VRES17
J201 Connector
2P2.54
13-12502-00
J202 Connector
2P2.54
13-12502-00
J203 Connector
2P2.54
13-12502-00
P201A Housing 8PIN 13-13908-00
BLKCON
.
155/VH/TM1SQ/W
.
250/
8
P202A Housing 8PIN 13-13908-00
BLKCON
.
155/VH/TM1SQ/W
.
250/
8
P203A Connector
10P2.0-A35B
14-97310-00
PHB-2.0A-10Y
P204B Housing
MOLEX 52807 RIGHT
ANGLE/NON-ZIF/TOP
CONTACT STYLE/16PIN
FPC1.0-16P)
13-21016-02
BLKCON.100/VH/TM2SQB/W.300
/116
P205B Housing
MOLEX 52807 RIGHT
ANGLE/NON-ZIF/TOP
CONTACT STYLE/16PIN
FPC1.0-16P)
13-21016-02
BLKCON.100/VH/TM2SQB/W.300
/116
P206B Housing FPC-1.0-16P/1.0-11-16P 13-21016-04
BLKCON.100/VH/TM1SQ/W.200/
16
P207A Connector Ribbon
6P2.0-A100B 1569-26AWG
14-52506-00
P208B Housing 5PIN7.5-C 13-27505-00
BLKCON
.
295/VH/TM1SQ/W
.
600/
5
P209B Housing 5PIN3.96-C 13-23905-00
BLKCON.156/VH/TM1SQB/W.355
/5
G2G1 Ground Solder Tap GND-8 32-28042-00
F201 Fuse T1.6AL/250V 20-12162-01 T1.6AL/250V
F202 Fuse T1.6AL/250V 20-12162-01 T1.6AL/250V
POT
CONNECTOR
FUSE
ELECTRICAL PARTS LIST
- 35 -
