62
SPEAKER BOARD
ASSEMBLY
PC BOARD
1501 * AH PCB-N0910C-SPK PCB ASSY SPEAKER N0910C
1501 * C PCB-N0911C-SPK PCB ASSY SPEAKER N0911C
TERMINALS
1502 * AH 2113-1663-0 4P SPEAKER TERMINAL R/B W/BANANA
1503 * AH 2113-1664-0 6P SPEAKER TERMINAL R/B W/BANANA
1502 * C 2113-1655-0 4P SPEAKER TERMINAL R/B
1503 * C 2113-1656-0 6P SPEAKER TERMINAL R/B
CAPACITORS
C594-R596 153F-102J-5-IM CM 50V 1000pF 5% RL 5x7
C851-C852 150F-331K-5-GE CC 50V 330pF 10% RL 4x3
WAFERS
J503B 2102-101S-004 WAFER 10P P2.5 ST. (COULOMB)
J801B 2102-081S-004 WAFER 8P P2.5 ST.
S-VIDEO BOARD
ASSEMBLY
PC BOARD
1401 PCB-N0910C-SVD PCB ASSY S-VIDEO N091XC
CONNECTORS
1402-1406 2113-1183-0 1P DIN CONNECTOR HDC-050
SWITCH
1407 5200-3171-0-01 DPDT SLIDE SW.SK-22F28-G9TS
CAPACITORS
C401 150F-223Z-5-UG CC 50V 0.022µF +80/-20% RL 11x4
C404 157F-225M-5-GM CE 50V 2.2µF 20% RL 4x7
C405 157C-477M-5-OU CE 10V 470µF 20% RL 8x11
C406 157F-225M-5-GM CE 50V 2.2µF 20% RL 4x7
C407 157C-477M-5-OU CE 10V 470µF 20% RL 8x11
C408-C413 157F-225M-5-GM CE 50V 2.2µF 20% RL 4x7
C414 157D-476M-5-IU CE 16V 47µF 20% RL 5x11
C415 157C-477M-5-OU CE 10V 470µF 20% RL 8x11
C416-C417 157F-225M-5-GM CE 50V 2.2µF 20% RL 4x7
C418 157D-106M-5-GM CE 16V 10µF 20% RL 4x7
C419 153F-223J-5-LQ CM 50V 0.022µF 5% RL 6.5x9
C420-C421 150F-223Z-5-UG CC 50V 0.022µF +80/-20% RL 11x4
C423-C424 157B-227M-5-KW CE 6.3V 220µF 20% RL 6x12
C429 15CH-300J-5-IG CTC 0/60 30pF 5% RL 5x4
C429A 15CH-050D-5-GG CTC 0/60 5pF 0.5pF RL 4x4
C430 15CH-300J-5-IG CTC 0/60 30pF 5% RL 5x4
C430A 15CH-050D-5-GG CTC 0/60 5pF 0.5pF RL 4x4
C431-C432 15CH-270J-5-GG CTC 0/60 27pF 5% RL 4x4
C433-C435 150F-470J-5-IF CC 50V 47pF 5% RL 5x3.5
C436 157F-105M-5-GM CE 50V 1µF 20% RL 4x7
C440 157D-476M-5-IU CE 16V 47µF 20% RL 5x11
C442 157B-107M-5-KM CE 6.3V 100µF 20% RL 6x7
C443 150F-103K-5-II CC 50V 0.01µF 10% RL 5x5
C444 150F-474M-5-II CC 50V 0.47µF 20% RL 5x5 MONO
C445 157B-107M-5-KM CE 6.3V 100µF 20% RL 6x7
C446 157F-474M-5-GM CE 50V 0.47µF 20% RL 4x7
C447 150F-470J-5-IF CC 50V 47pF 5% RL 5x3.5
C448 150F-474M-5-II CC 50V 0.47µF 20% RL 5x5 MONO
Reference No. Part No. Description
