NAD T585 - Exploded View Parts List

REF.NO. PART NO. DESCRIPTION Qty. REF.NO. PART NO. DESCRIPTION Qty.
C001 67-042002-1 Chassis 1 P001 70-051005-0 Heatsink 2
C002 01-58501-20 Decode
Board(C Version) 1
01-58501-10 Decode
Board(AH Version) 1
C003 01-55502-20
Video Board(C Version) 1 FP01 65-051011-0 IR Bracket 1
01-55502-10 Video Board(AH Version) 1 FP02 23-55559-00 VFD 1
C004 01-55503-00 PSU Board 1 FP03 75-051001-0 Display Bracket 1
C005 36-58513-00 Loader with 313 laser Pick Up 1
C006 77-042002-0 DVD Door 1
C007 75-010004-1 Foot 4 S001 61-023206-1 Self Taping Screw (BTB3X6) 4
C008 78-001002-0 Foot Pad 4 S002 61-023106-2 Self Taping Screw (STB3X6) C:38
61-023106-2 Self Taping Screw (STB3X6) AH:33
S003 61-023108-0 Self Taping Screw (STB3X6) 4
F001 67-042001-0 Fascia 1 S004 61-373506-0 Machine Screw (MB3X6W.S-Ni) 10
F002 67-042002-0 End Cap L 1 S005 61-083106-0 Self Taping Screw (STPW 3X6) 4
F003 67-042003-0 End Cap R 1 S006 61-073108-0 Self Taping Screw (STO3X8) 2
F004 76-003001-0 Led Lens 1 S007 61-023208-0 Self Taping Screw (BTB3X8) 7
F005 77-026002-0 Power Button Bezel 1 S008 61-084108-0 Self Taping Screw (STPW 4X8) 4
F006 77-026001-0 Power Button 1 S009 61-023508-0 Machine Screw (MB3X8) 2
F007 76-009001-0 VFD W indow 1 S010 62-010302-2 Nut(M3) 2
F008 74-042001-0 Button Bezel 1
F009 77-042001-0 Button 1
F010 01-58504-00 FPP 1
F011 01-58507-00 Led Board 1
F012 66-042001-0 Subfascia 1
R001 67-042004-0 Rear Panel (C Version) 1
67-042005-0 Rear Panel (AH Version) 1
R002 11-01101-03 Rocker Switch 1
R003 17-07002-02 AC Inlet 1
R004 01-55506-20 Scart Board(C Version) 1
R005 01-55505-00 RS232 Board 1
T001 67-042016-0 Top Cover
(titanium) 1
RS01 66-010010-0 Bracket 2
SC01 66-010010-0 Bracket 2
SC02 66-051003-0 Scart Bracket 1
2.Exploded view parts list
2-
67-042006-0 Top Cover (grey)
