NAD T744 - Page 60

60
Reference No.
Database Part No. Descri
p
tion
SMD RESISTORS
R234 02-007-0042-00 RES SMD 1K OHM 5% 1/16W 0603
R208 02-007-0089-00 RES SMD 0 OHM +/-5% 1/10W 0805
R216 02-007-0094-00 RES SMD 1K OHM 1% 1/4W 1206
R238 02-007-0132-00 RES SMD 12K OHM 5% 1/16W 0603
R220,R256-R259,R261,R263- 02-007-0139-00 RES SMD 4.7K OHM 5% 1/16W 0603
R233 02-007-0140-00 RES SMD 47K OHM 5% 1/16W 0603
R241-R242 02-007-0141-00 RES SMD 100 OHM 5% 1/16W 0603
R221,R230 02-007-0144-00 RES SMD 2.2K OHM 5% 1/16W 0603
R201-R207,R213,R219,R223-
R224,R226-R227,R229,R231-
02-007-0148-00 RES SMD 10K OHM 5% 1/16W 0603
R255 02-007-0268-00 RES SMD 56K OHM 5% 1/16W 0603
R222,R225 02-007-0288-00 RES SMD 0 OHM 5% 1/16W 0603
R217,R218 02-007-0294-00 RES SMD 470 OHM 5% 1/16W 0603
R225 02-007-0297-00 RES SMD 560 OHM +/-1% 1/16W 0603
R251,R252 02-007-0299-00 RES SMD 10M OHM +/-5% 1/16W 0603
SMD CAPACITORS
C201,C202,C213,C215-
C220,C222,C229,C256
03-009-0075-00 CAP CER SMD 0.1uF 50V 20% Y5V 0603
C241,C242 03-009-0112-00 CAP CER SMD 1nF 50V 10% X7R 0603
C251-C254 03-009-0116-00 CAP CER SMD 33
p
F 50V 10% X7R 0603
LED BOARD
PCB ASSEMBLY 27-915-0744-90 T744AH
(
US
)
LED Board Assembl
y
TRANSISTORS
Q213 05-001-0078-00 Transistor SS NPN HFE30 250MHs SPT
Q211,Q212 05-001-0082-00 Transistor SS PNP HFE30 250MHs SPT
TACT SWITCH
S220 11-007-0060-90 SW TACT NO 1P1T 50mA/12V VER H=7mm
LED
D211 12-006-0156-90
LED GRN-AMB-RED CIRCULAR 5X8.7MM BL-
BG0A0D13C4V COMMON CATHODE
DIODES
D221,D222 04-001-0001-00
Diode 1N4148 DO-35 0.15A/100 Signal Switching
Diode
LED BOARD
PCB ASSEMBLY 27-901-0744-90 PCB Ass
y
T744AH
(
US
)
Normal Main Board
CAPACITORS
C701,C724 03-002-0057-00 CAP ELEC EGH 4700uF 25V 20% 105C RAD ST7.5
C702,C705,C706,C716,C725 03-002-0066-00 CAP ELEC KM 1000uF 25V 20% 105C 10X20
C707 03-002-0078-00 CAP ELEC KM 2200uF 35V 20% 105C VER
C711-C713,C741 03-002-0090-00 CAP ELEC KM 1000uF 50V 20% 105C RAD
C734,C735 03-002-0129-00
CAP ELEC SS 10uF 16V 20% 85C RAD HEIGHT
=7mm MAX
C719 03-002-0130-00 CAP ELEC KM 100uF 16V 20% 105C RAD ST5
C710 03-002-0144-00 CAP ELEC SS 47uF 50V 20% 85C RAD 8 X 9mm
C704 03-002-0147-00 CAP ELEC 4700uF 35V 105C RAD
C715 03-004-0090-00 CAP MPF 1uF 63V +/-5% MEM
