NAD T744 - Page 61

61
Reference No. Database Part No. Descri
p
tion
DIODES
D701-D710 04-001-0003-00 DIODE RECT 1A/1000V DO41 WIN4007 REEL
D715 04-005-0020-90 DIODE BRI 4A/70V RS402L
D711 04-002-0045-90 DIODE ZENER BZX55 30V 1/2W 5% DO35 BZX55-
TRANSISTORS
Q701 05-001-0065-00 XTR PW NPN 1A/100V TO-126 2SD600KE
REGULATORS
U705,U704,U701 01-004-0048-00 IC VOLT REG 5V 1A TO-220 NJM7805FA ISOWATT
U702,U707 01-004-0049-00 IC VOLT REG 12V 1A TO-220 NJM7812 ISOWATT
U703 01-004-0051-00 IC VOLT REG TO-220F NJM7912
JUMPER BARS
JP701-JP702 17-016-0043-90 JUMPER BAR DIA1.5 X 25 R.1
MULTI-CHANNEL BOARD
PCB ASSEMBLY 27-923-0744-90 T744AH
(
US
)
Multi-Channel Board Assembl
y
CAPACITORS
C607 03-002-0073-00
CAP ELEC GS 22uF 16V 20% 85C RAD HEIGHT =
7mm MAX
C755,C775 03-002-0102-00 CAP ELEC 2.2uF 50V 20% NON-POLAR 99NPO2020
C780-C793 03-002-0129-00
CAP ELEC SS 10uF 16V 20% 85C RAD HEIGHT
=7mm MAX
C627,C628,C633,C634 03-002-0133-00
CAP ELEC SS 100uF 16V 20% 85C RAD HEIGHT =
7mm MAX
C677,C678,C689,C690 03-002-0143-00
CAP ELEC SS 47uF 16V 20% 85C RAD HEIGHT =
7mm MAX
C759,C760,C769,C770,C777,C778,C77 03-004-0031-00 CAP MPF 0.1uF 63V +/-5% MEM
C767,C768 03-004-0116-00 CAP MPF 0.0033uF 100V +/-5% MEM
C763,C764 03-004-0117-00 CAP MPF 0.047uF 100V +/-5% MEM
C757 03-004-0118-00 CAP MPF 0.082uF 100V +/-5% MEM
TRANSISTORS
Q601 05-001-0094-90
TRANSISTOR 8050C NPN TO-92 HFE 120-200 1.5A
40V
Q602 05-001-0095-90 XTR SS PNP HFE 120-200 200MHz TO-92 8550C
INDUCTORS
L601,L602 07-002-0133-90 IND CHOKE 100uH +/-10% EC24-101K
RCA JACKS
M602 15-003-0023-90 RCA JACK 2 B/B PCB MOUNT GOLD
(
W/SHIELD
)
M601 15-003-0027-90 RCA JACK 4 R-R/W-W PCB MOUNT GOLD
M603 15-003-0029-90
RCA JACK 6 R-R-R/W-W-W PCB MOUNT GOLD
RCA-653D-04
(
W/COVER
)
ICS
U601 01-028-0001-90
IC SOUND PROCESSOR 7.1CH VOL+TONE SMD
QFP M61516FP
U604,U605 01-014-0027-00
IC NJM4560M SO 8 PIN DUAL OP AMP SMD
NJM4560M
RESISTORS
R611,R612,R616 02-002-0131-00 RES MF 20K OHM 1% 1/6W
R609,R610,R615 02-002-0135-00 RES MF 33K OHM 1% 1/6W
R613,R614 02-002-0136-00 RES MF 75K OHM 1% 1/6W
