NAD T744 - Page 62

62
Reference No. Database Part No. Descri
p
tion
DIODES
D602,D604 04-002-0047-90
DIODE ZENER BZX55 7.5V 1/2W 5% DO35 BZX55-
C7.5V
PRE-OUT BOARD
PCB ASSEMBLY 27-924-0744-90 T744AH
(
US
)
Pre-Out Board Assembl
y
CAPACITORS
C624-C625,C640, C645,C650,C655,
C670, C675,C693-C698
03-002-0073-00
CAP ELEC GS 22uF 16V 20% 85C RAD HEIGHT =
7mm MAX
C647,C652,C672 03-002-0129-00
CAP ELEC SS 10uF 16V 20% 85C RAD HEIGHT
=7mm MAX
C687,C684,C685,C688 03-002-0141-00 CAP ELEC GR 330uF 16V 20% 85C RAD
C637,642,C667,C692,C691,C679,C680 03-002-0143-00
CAP ELEC SS 47uF 16V 20% 85C RAD HEIGHT =
7mm MAX
C626 03-002-0150-00 CAP ELEC SS 220uF 16V 20% 85C 8x9mm RAD
DIODES
D611-D614 04-001-0003-00 DIODE RECT 1A/1000V DO41 WIN4007
D601,D605,D606,D608,D609 04-001-0001-00 DIODE SW 4NS DO35 1N4148
D619-D621 04-002-0047-90 DIODE ZENER BZX55 7.5V 1/2W 5% DO35
RESISTORS
R636,R643,R687 02-002-0129-00 RES MF 1K OHM 1% 1/6W
R648,R655,R679 02-002-0130-00 RES MF 1.5K OHM 1% 1/8W
R671,R686,R685 02-002-0132-00 RES MF 2.7K OHM 1% 1/6W
R672 02-002-0133-00 RES MF 330 OHM 1% 1/6W
R667-R669,R684, R690,R678,R642,
R654,R647,R635
02-002-0134-00 RES MF 3.3K OHM 1% 1/6W
JUMPERS
R625-R628, R657-R662 17-016-0080-90
JUMPER WIRE DIS 0.5MM FOR L SMALLER THAN
14MM ROLL
TRANSISTORS
Q608-Q611,Q614-Q615,Q617,Q631-
Q635
05-001-0074-00
TRANSISTOR SS NPN HFE200-700 30MHz SPT
RN1241A
Q636,Q637 05-001-0075-00 TRANSISTOR SS NPN HFE200-700 30MHz
Q639 05-001-0078-00
TRANSISTOR SS NPN HFE30 250MHz SPT
DTC114ESATP
Q616,Q618,Q622,Q624,Q638 05-001-0082-00
TRANSISTOR SS PNP HFE 30 250MHz SPT
DTA114ESATP
INDUCTORS
L602-L606,L609,L610 07-002-0132-90 IND CHOKE 10uH 10% EC36 EC36-100K
RCA JACKS
M608,M612 15-003-0022-90 RCA JACK 2 B/B PCB MOUNT GOLD RS-213G-
M609 15-003-0024-90 RCA JACK 2 R-W PCB MOUNT GOLD
(
W/O COVER
)
M607 15-003-0028-90 RCA JACK 4 R-W/R-W PCB MOUNT GOLD
ICS
U609,U610,U612,U614,U615 01-014-0027-00
IC NJM4560M SO 8 PIN DUAL OP AMP SMD
NJM4560M
SMD RESISTORS
P601, P602 02-007-0089-00 SMD R 0 OHM 1/8W 0805 5%
