NAD T744 - Page 63

63
Reference No. Database Part No. Descri
p
tion
SMD CAPACITORS
C747-C758 03-009-0075-00 CAP CER SMD 0.1uF 50V 20% Y5V 0603 TAPE
SMD DIODES
D615-D638 04-007-0039-90 DIODE ZENER SMD 12V 500mW 5% SOD123
POWER SUPPLY BOARD
PCB ASSEMBLY*AH, 27-903-0744-90 PCB Ass
y
T744AH
(
US
)
Power Su
pp
l
y
Board
PCB ASSEMBLY*C,CT 27-904-0744-90 PCB Ass
y
T744C
(
CE
)
Power Su
pp
l
y
Board
RESISTOTRS
R754*AH 02-001-0451-00 RES CONDUCTIVE PATH 3.9M OHM 1/2W 5% 250V
R751 02-004-0014-00 RES FUSIBLE 0.22 OHM 10% 1/2W
CAPACITORS
C755 03-002-0146-00 CAP ELEC GR 4700uF 25V 20% 85C RAD
C752 03-002-0148-00
CAP ELEC SS 4.7uF 50V 20% 85C RAD
HEIGHT=7mm MAX
C753 03-004-0115-00 CAP M
p
F 0.001uF 63V 5% DMF 5 SERIES
C754,C763 03-007-0014-00
HC CER CAP 0.01uF/250VAC ±20% Y5V RAD
JY16F103MK02 UL/CSA/VDE
DIODES
D751-D756 04-001-0003-00 DIODE RECT 1A/1000V DO41 WIN4007 REEL
TRANSISTORS
Q751 05-001-0072-00 XTR SS NPN HEF 100 200MHz TO-92 C1815Y
RELAY
M751B 07-005-0038-90
RELAY POWER DC12V 20A 220VAC 1P1T PCB ME-
14FW-012-HS UL/CUL
STANDBY TRANSFORMER
T751 10-005-0186-90 TRANSFORMER PW EI-35 100V/220V T05382B ISS 2
FUSES
F751*AH 20-001-0075-90 FUSE TIME-LAG 7A 250V 5 X 20mm SIC UL/CSA
F751*C,CT 20-001-0071-90
FUSE TIME-LAG 4A 250V 5 X 20mm TSD
UL/CSA/VDE/CCC WALTER
F752*AH 20-001-0076-90
FUSE 1.6A 250V TIME LAG LBC 5x20mm TSD
UL/CSA/VDE/SEMKO
F752*C,CT 20-001-0069-90
FUSE TIME-LAG 800mA 250V 5x20mm TSD
UL/CSA/VDE/CCC WALTER
JUMPERS
JP1,JP,JP6,JMP1,JMP2*AH 17-016-0077-00 Jum
p
er wire Dia. 0.5mm L=52.0mm
JP3,JP7,JMP1,JMP2*C,CT 17-016-0077-00 Jum
p
er wire Dia. 0.5mm L=52.0mm
