NAD T744 - Page 64

64
Reference No. Database Part No. Descri
p
tion
SECONDARY BOARD
PCB ASSEMBLY 27-926-0744-90 PCB Ass
y
T744AH
(
US
)
Normal Secondar
y
Board
RESISTORS
R781-R785 02-010-0011-00 RES MO 0.22 OHM 5% 1/2W
CAPACITORS
C790,C791 03-002-0149-00 CAP ELEC LP 8200uF 63V 20% 85C RAD
C781-C785,C787-C788 03-004-0031-00 CAP MPF 0.1uF 63V +/-5% MEM
DIODES
D781 04-005-0015-00 BRIDGE RECTIFIER 25A 400V BR254W BR-25W
JUMPER BARS
J3,J4 17-016-0043-90 JUMPER BAR DIA1.5 X 25 R.1
FUSES
F781,F782 20-001-0077-90 FUSE TIME-LAG 10A/250VAC 5 X 20mm UL/VDE 5D
SPEAKER BOARD
PCB ASSEMBLY 27-927-0744-90 T744AH
(
US
)
S
p
eaker Board Assembl
y
CAPACITORS
C563,C825,C562,C561,C826,C568,C56 03-001-0066-00 CAP CER HIK 3.3nF 50V 10% B RAD ST7.5
SPEAKER TERMINAL
M8101 16-001-0429-90
SPEAKER TERMINAL 6P BINDING R/B W/O PLUG
KF-J5000-06
M5101,M5102 16-001-0430-90
SPEAKER TERMINAL 4P BINDING R/B W/O PLUG
KF-J5000-04
S-VIDEO BOARD
PCB ASSEMBLY 27-929-0744-90 T744AH
(
US
)
S-Video Board Assembl
y
CAPACITORS
C4145 03-002-0073-00
CAP ELEC GS 22uF 16V 20% 85C RAD HEIGHT =
7mm MAX
C4151 03-002-0129-00
CAP ELEC SS 10uF 16V 20% 85C RAD HEIGHT
=7mm MAX
C4149,C4134 03-002-0132-00
CAP ELEC SS 100uF 10V 20% 85C RAD HEIGHT =
7mm MAX
C4101,C4102,C4103,C4104,C4105,C4
106,C4107,C4115,C4158
03-002-0133-00
CAP ELEC SS 100uF 16V 20% 85C RAD HEIGHT =
7mm MAX
C4116 03-002-0135-00 CAP ELEC GS 1000uF 10V 20% 85C RAD ST5
C4141,C4133,C4137 03-002-0137-00
CAP ELEC SS 1uF 50V 20% 85C RAD HEIGHT=
7mm MAX
C4144 03-002-0138-00 CAP ELEC. SS 0.1uF 50V 20% 85C RAD
C4162,C4167,C4171,C4173 03-002-0139-00 CAP ELEC SS 220uF 10V 20% 85C RAD
C4150 03-002-0143-00
CAP ELEC SS 47uF 16V 20% 85C RAD HEIGHT =
7mm MAX
C4108,C4156,C4163,C4164,C4168,C4
169
03-002-0145-00 CAP ELEC GR 470uF 10V 20% 85C RAD ST5
C4153,C4157 03-002-0157-00 CAP ELEC SS 2.2uF 50V 20% 85C RAD
