NAD T744 - Page 65

65
Reference No. Database Part No. Descri
p
tion
C4146,C4136 03-004-0049-00 CAP M
p
F 0.47uF 63V +/-5% DMF 5 SERIES
C4175 03-004-0117-00 CAP MPF 0.047uF 100V +/-5% MEM
C4138 03-011-0001-00
CAP TRIMMER 20pF 20% SEALED HORI.
PITCH=5mm CVN620
TRANSISTORS
Q4132 05-001-0072-00 TRANSISTOR SS NPN HEF 100 200MHz TO-92
Q4122,Q4131 05-001-0073-00
TRANSISTOR SS NPN HFE 68 30MHz SPT
DTC144ESATP
Q4105,Q4106,Q4133,Q4128,Q4130,Q4
113,Q4114,Q4121,Q4124,Q4125
05-001-0075-00
TRANSISTOR SS NPN HFE200-700 30MHz
2SC2878A
Q4109,Q4120,Q4123 05-001-0076-00 TRANSISTOR SS NPN HFE20 250MHz
Q4115,Q4126,Q4127 05-001-0077-00
TRANSISTOR SS NPN HFE270-560 180MHz
2SC1740STPS
Q4107,Q4108,Q4116-
Q4119,Q4134,Q4135
05-001-0081-00
TRANSISTOR SS PNP HFE 270-560 140MHz
2SA933ASTPS
Q4101-Q4104 05-001-0095-90
TRANSISTOR SS PNP HFE 120-200 200MHz TO-92
8550C
INDUCTORS
L4102 07-002-0134-90 IND CHOKE 22uH 10% EC24-220K
L4101 07-002-0135-90 IND CHOKE 5.6uH +/-10% EC24-5R6K
CRYSTALS
X4101 14-002-0019-00
CRYSTAL 14.31818MHz 30ppm 32pF HC-49S 01-
CR1-02-14M318-32
X4102 14-002-0021-00
CRYSTAL 17.734475MHz 30ppm 32pF HC-49/S 01-
CR1-02-17M734475-32-3050
DIN JACKS
M411,M412,M413,M414,M418 15-017-0001-90 DIN JACK 1 BLACK PCB MOUNT MD-113
ICS
U4101 01-023-0001-90 IC OSD DIP30SD LC74763-9012
U4102,U4103 01-012-0062-00
IC LOGIC 8-CHANNEL ANALOG MUX/DEMUX SMD
74HC4051D
DIODES
D4101-D4109 04-001-0001-00 DIODE SW 4NS DO35 1N4148
TRIGGER BOARD
PCB ASSEMBLY 27-930-0744-90 T744AH
(
US
)
Tri
gg
er Board Assembl
y
REGULATORS
U353 01-004-0047-00 I.C. REG 0.1A TO-92 AZ317LZ
U352 01-004-0050-00 IC VOLT REG 12V 100mA TO-92 ML78L12A
RESISTORS
R358,R359 02-010-0012-00 RES MO 150 OHM 5% 2W
DIODES
D354-D360 04-001-0003-00 DIODE RECT 1A/1000V DO41 WIN4007 REEL
TRANSISTOR
Q351 05-001-0076-00 TRANSISTOR SS NPN HFE20 250MHz
SLIDE SWITCH
S351 11-002-0042-90 SW SLIDE 2P2T RIGHT L=9 JSK022N09-G09
