NAD T744 - Page 66

66
Reference No. Database Part No. Descri
p
tion
PHONE JACKS
M351,M352,M353,M354,M355,M357 15-002-0028-90 PHONE JACK 1 BLACK PCB MOUNT 3.5mm RIGHT
DIODES
D351-D353 04-002-0040-00
DIODE ZENER BZX79 5.1V 1/2W 5% DO35 BZX79-C
5.1V
VIDEO -6 BOARD
PCB ASSEMBLY 27-931-0744-90 T744AH
(
US
)
Video-6 Board Assembl
y
CAPACITORS
C4401,C4402,C4403 03-002-0133-00
CAP ELEC SS 100uF 16V 20% 85C RAD HEIGHT =
7mm MAX
JACKS
J4401 15-002-0029-90 PHONE JACK D6.3 1 PCB MOUNT GOLD
M4401 15-003-0018-90
RCA JACK 1 YELLOW PCB MOUNT GOLD (W/O
COVER
)
M4404 15-003-0019-90 RCA JACK 1 RED PCB MOUNT GOLD
(
W/O COVER
)
M4403 15-003-0020-90 RCA JACK 1 WHITE PCB MOUNT GOLD
M4402 15-017-0001-90 DIN JACK 1 BLACK PCB MOUNT MD-113
COMPOSITE VIDEO BOARD
PCB ASSEMBLY 27-920-0744-90
PCB Assy T744AH (US) Composite Video Board
Assembl
y
CAPACITORS
C4201,C4202,C4203,C4205,C4207 03-002-0133-00
CAP ELEC SS 100uF 16V 20% 85C RAD HEIGHT =
7mm MAX
C4208 03-002-0135-00 CAP ELEC GS 1000uF 10V 20% 85C RAD ST5
C4221,C4224 03-002-0139-00 CAP ELEC SS 220uF 10V 20% 85C RAD
C4204,C4206,C4222,C4223 03-002-0145-00 CAP ELEC GR 470uF 10V 20% 85C RAD ST5
TRANSISTORS
Q4201,Q4205 05-001-0075-00 TRANSISTOR SS NPN HFE200-700 30MHz
Q4202,Q4206 05-001-0076-00 TRANSISTOR SS NPN HFE20 250MHz
Q4203,Q4204,Q4207 05-001-0081-00
TRANSISTOR SS PNP HFE 270-560 140MHz
2SA933ASTPS
Q4209,Q4210 05-001-0095-90
TRANSISTOR SS PNP HFE 120-200 200MHz TO-92
8550C
RCA JACKS
M421,M422 15-003-0026-90
RCA JACK 4 Y-Y/Y-Y PCB MOUNT GOLD RS-454-03
(
W/SHIELD
)
IC
U4201 01-012-0062-00
IC LOGIC 8-CHANNEL ANALOG MUX/DEMUX SMD
74HC4051D
D4201,D4202 04-001-0001-00 DIODE SW 4NS DO35 1N4148
SMD RESISTORS
J4201,J4202 02-007-0089-00 RES SMD 0 OHM +/-5% 1/10W 0805
