ENGLISH
In case you simply cannot wait to experience the performance of your new NAD T 752 receiver, we provide
the following “Quickstart” instructions to get you underway. The steps below connect your DVD player to the
T 752’s DVD input; be sure to read “Input Setup”, below.
• Connect the T 752’s composite video or S-Video MONITOR OUT jack to your TV/monitor’s corresponding
input.
• Connect your DVD player’s composite video or S-Video output to the T 752’s corresponding DVD input.
• Connect the DVD player’s optical digital output to the T 752’s optical DIGITAL IN 1 input.
• Connect your left and right front speakers to the T 752’s FRONT L and R outputs, being sure to connect
red to red (“+”) and black to black (“-”), with care to avoid stray wires or strands crossing between
terminals. (Connect center and surround speakers as well, if you like). If your system includes a powered
subwoofer, connect the T 752’s AUDIO PRE-OUT SW1 jack to its line input.
• Press in the main power switch (green pushbutton) on the T 752’s front panel (this puts the T 752 into
STANDBY mode and illuminates an amber LED to indicate it is ready to receive remote commands), then
use the HTR 2’s [ON] key to power up the receiver. Be sure the TV/monitor is powered up, with the correct
input selected.
• Start playback of the DVD player. Press the HTR 2 remote’s [Amp] Device Selector key, and then its (red)
DVD/numeric 1 key to select the DVD input. You should hear multichannel or stereo sound, and see an
image on the TV/monitor. (If one or the other fails to appear, you may need to use the receiver’s on-screen
menu system to check assignment of audio, video, and digital inputs; see “Configuring the T 752”,
below.)
Enjoy the movie or music, but be sure to set aside time to read this manual thoroughly, and to set up,
calibrate, and configure your T 752 carefully and completely.
PLAPLA
PLAPLA
PLA
Y A DVD MOVIEY A DVD MOVIE
Y A DVD MOVIEY A DVD MOVIE
Y A DVD MOVIE
QUICKSTART
