FPΣ 13.1 Table of Specifications
13 - 3
13.1 Table of Specifications
This section contains the general and performance specifications for the FPΣ.
13.1.1 General Specifications
Item Description
Rated operating voltage 24 V DC
Operating voltage range 21.6 to 26.4 V DC
Allowed momen-
C32 4 ms at 21.6 V, 7 ms at 24 V, 10 ms at 26.4 V
tary power off time
C24 3 ms at 21.6 V, 5 ms at 24 V, 8 ms at 26.4 V
Ambient temperature 0 to +55 °C/32 to +131 °F
Storage temperature –20 to +70 °C/–4 to +158 °F
Ambient humidity 30 to 85 % RH (non-condensing)
Storage humidity 30 to 85 % RH (non-condensing)
Breakdown
voltage
C32 Between input/output terminals and power supply terminal/
function earth
500 VAC for 1 minute
Between input terminal and output terminal
C24 Between input terminals (X0 to X7)/input terminals (X8 to
XF) and power supply terminal/function earth
500 VAC for 1 minute
Between output terminals and power supply terminal/func-
tion earth
1500 VAC for 1 minute
Between input terminals (X0 to X7) and input terminals (X8
to XF)
500 VAC for 1 minute
Between input terminals (X0 to X7)/input terminals (X8 to
XF) and output terminals
1500 VAC for 1 minute
Insulation
resistance
C32 Between input/output terminals and power supply terminal/
function earth
Min. 100Ω (measured
with a 500 V DC megger)
Between input terminal and output terminal
C24 Between input terminals (X0 to X7)/input terminals (X8 to
XF) and power supply terminal/function earth
Between output terminals and power supply terminal/func-
tion earth
Between input terminals (X0 to X7) and input terminals (X8
to XF)
Between input terminals (X0 to X7)/input terminals (X8 to
XF) and output terminals
Vibration resistance 10 to 55 Hz, 1 cycle/min: double amplitude of 0.75 mm/ 0.030 in., 10 min on 3 axes
Shock resistance Shock of 98 m/s
2
or more, 4 times on 3 axes
Noise immunity 1,000 Vp-p with pulse widths 50 ns and 1 µs (based on in-house measurements)
Operating condition Free from corrosive gases and excessive dust
