nama M1 - Assembly

10
ASSEMBLY
STEP 1
ASSEMBLE THE
CHAMBER SET
STEP 1
(CONT’D)
Blade Frame
Filter Basket
Turn to close lid
completely until
the arrow aligns
with the lock
symbol.
Chamber
Chamber Lid
Chamber
Place the chamber lid
on top of the chamber
with the arrow aligned
to the unlock symbol.
Insert the blade frame
into the lter basket,
then insert the set into
the chamber.
