3-4 Test Mode
1. Open the coin door for access to the service bracket, then slide the test switch
to "ON". The "Switch Test Screen" appears on the monitor display.
2. Pressing the service button steps through the test screens.
3. When testing is finished ensure that the test switch is returned to the "OFF"
position to return to Game Screen
The Test Switch must always be "OFF" during normal game mode.
3-4-1 Switch Test
1. Enter test by switching
the Test Switch ON. The
"Switch Test Screen"
appears.
2. The corresponding
writing on the test screen
will change to red while
the switch under test is
activated.
3-4-2 Gun and Lamp Test
1. Advance to the GOUT Test Screen
from the Switch Test Screen by
pressing the service button on the
service bracket.
2. Pressing the 1 Player Start Button
selects the test required. The
selected test will change to red.
3. Pressing the 2 Player Start Button
will activate the test.
1P/2P Blowback - Gun recoils each
time 2 player start switch is
pressed
Auto Blowback - Both guns recoil
constantly when 2 player start
button is pressed. Pressing start
button again turns the test off.
Flash - Not Used
SWITCH TEST
DIP SW 12 OH
COIN1 COUNT 0H
COIN2 COUNT 0H
1P SWITCH 2P SWITCH
TRIGGER TRIGGER
START START
GOUT TEST
1P BLOWBACK
OFF
2P BLOWBACK
OFF
1P START LAMP
NO
2P START LAMP
NO
FLASH
NO
AUTO BLOWBACK
NO
4
