Page 14
6-3 Test Mode
1. Open the coin door and slide the test switch ON. The Menu Screen will
be displayed on the monitor.
2. Select the test required by using the select up/down switch. The colour of
the selected test will change.
3. Activate the test by pressing the Enter switch. Select EXIT in each test
to return to the Menu Screen.
4. After testing is completed, slide the test switch to the OFF position to
return to normal game mode.
The Test Switch must always be in the OFF position for normal game mode.
MENU
COIN OPTIONS ............................ Used to set the price of play
GAME OPTIONS ............................ Used to set the game options
I/O TEST ............................ Used for testing switches & Gun
MONITOR TEST ............................ Used for setting the monitor
SOUND TEST ............................ Used for setting the volume
ADS DATA ............................ Used to view bookkeeping
OTHERS ............................ Used for testing the PCB
LINK MALFUNCTION 1 2 3 .............. (a)
GAME DIFFICULTY L/R:NOT THE SAME ............ (b)
}
Do not appear when OK
The internal batterys dead....................... (c)
SELECT SW : CHOOSE ENTER SW : ENTER
(a) Error message related to link play
A message appears if the link play is defective. The number displayed
represents the type of error
when 1 or 2 is displayed either the main PCB or memory PCB may be
defective. Contact your distributor.
If 3 is displayed, the software version on the left game PCB is different
from that on the right game PCB. Contact your distributor.
(b) Error message related to difficulty settings
A message appears if the difficulty settings of the left and right game
PCBs are different. Enter GAME OPTIONS inthe test mode and set
both PCBs the same.
(c) Low battery display
A message appears if the Main PCB battery is faulty. Contact your
distributor.
