Page 23
6-3-5 Sound Test
1. Select I/O TEST on the menu screen to switches and lamps. The
following screen is displayed.
2. Use the Select Up/Down switch to choose the required item then press
the Enter button.
3. Use the Up/Down switch to change the setting.
4. Press the Enter button after the changes have been made to return to the
options.
5. Select EXIT and press the Enter button to return to the menu screen.
(a) Volume setting for left channel speaker. Settable from 0 ~ 64 with 0
quietest and 64 loudest.
(b) Volume setting for right channel speaker. Settable from 0 ~ 64 with 0
quietest and 64 loudest.
(c,) Each number will produce a different sound each time the Service
button is pressed. (for a maximum of ten seconds)
001 when selected will produce a sound from the left speaker only,
then the right speaker only and then both speakers together as a
stereo check. The message field shows which speaker is active.
(d) Displays the song No. details.
SOUND TEST
<DEFAULT IN GREEN>
VOLUME FRONT L SP (0~64) 40 .................................... (a)
FRONT R SP (0~64) 40 .................................... (b)
REQUEST SONG NO. 000 .................................. (c)
MESSAGE ........................................ (d)
EXIT
SELECT SW : CHOOSE ENTER SW : ENTER
SERVICE SW : REQUEST ON/OFF
