1. Handle: Offer convenient grip for adjusting direction of illumination.
2. USB Port: For updating firmware.
3. Display Screen: For displaying datas.
4. Right Knob: For selecting various options and adjusting the color temperature in the CCT mode.
5. Left Knob: For adjusting the DIM and adjusting parameters.
6. Button: MODE button for switching between CCT mode and EFFECT mode, MENU button for switching to the menu.
7. DMX In/Out: Connect to DMX adapter cable for DMX signal input and output.
(Note: DMX adapter cable is sold separately).
8. Fixture Body Input Socket: To connect a DC cable for connecting between fixture body and power supply.
9. Power Switch: To turn on/off the fixture.
10. Reflector: For concentrating light to improve the central illumination.
11. Umbrella Mount: For installing an umbrella.
12. Adjustable Handle: Tighten or release the tilt movement of the fixture on the yoke.
13. Yoke: For mounting the fixture on the light stand and adjusting the direction of illumination.
14. Bracket Fixing Knob: For locking the light fixture on the stand, and for pan adjustment of fixture.
15. Lock Catch: To lock or release the reflector or other accessories.
Detailed Description
