Usage
1. Installation and Detachment of Reflector
When installing the reflector, align
the reflector to the fixture's Bowens
mount, rotate the reflector in the
direction shown on the fixture until it
clicks into place.
When removing the reflector, push
and hold the lock catch and rotate
the reflector until the it is free to be
removed from the fixture.
Press the lock catch to remove the
reflector.
2. Installation of Umbrella
Loosen the adjustable handle. Insert the umbrella into the
umbrella mount.
Tighten the adjustable handle to
lock the umbrella.
