7
SETTING THE ALARM (ARMING) WHEN LEAVING
System Trouble
If you attempt to arm with a “SYSTEM TROUBLE” display alternating with an indicated trouble
code (e.g. “E02-00” (low battery); see SYSTEM TROUBLE ERROR CODES), a 3-second tone
will sound at the keypad. The window will display "CAN'T ARM SYSTEM, PRESS RESET KEY".
If you cannot correct the problem immediately, pressing
C will enable you to arm in this
condition. Be sure to call for service as soon as possible.
Area Arming (Optional)
Some systems may be divided, or partitioned, into smaller independent subsystems, which are
referred to as Areas. In a system that has been partitioned into multiple areas, one or more area
may be armed while others remain disarmed.
Manager's Mode (Optional)
The Manager's Mode allows the user to arm / disarm other areas in a partitioned system. To
arm/disarm a different area:
1. Press the numerical key representing the other area number.
2. Press
Gfollowed by J. The keypad will now provide status and control of that area.
3. Enter your User Code followed by
J to arm or disarm the area.
4. Press
G followed by J to return to the home area.
Global Arming (Optional) (Not available with GEM-P1632/816 panels)
To arm all areas simultaneously, press 9, G and enter your code followed by J.
To disarm all areas simultaneously, press
0, G and enter your code followed by J.
• The User Code must be valid in all area(s).
• If any zone is not secured, the keypad will display “CAN’T ARM SYSTEM, AREA X IN
TROUBLE”, where X indicates the number of the Area in trouble. All faulted zones in the
respective area(s) must be secured or bypassed. Note: If a system trouble is indicated, the
system cannot be armed using this method.
SYS/TRBL
LOW BATTERY
E02-00 SERVICE
SYS/TRBL
SYSTEM TROUBLE
SYS/TRBL
CAN’T ARM SYSTEM
PRESS RESET KEY
EXIT TIME 060
PLEASE LEAVE NOW
CAN’T ARM SYSTEM
AREA X IN TROUBLE
