NAPCO Gemini C-Series Control Panel Programming Instructions--Volume 1
NAPCO Security Group
Programming Instructions, Volume 1 Page 33
Enter User Codes (Press the R button to set cursor.)
Enter up to 195 User Codes with User Options, Authority Level and Output Control Options (if
necessary) for each code. Refer to the tables below and on the next page for available
data entries for User Options, Authority Level and Output Control Options. Note: All 195
Users must be assigned to areas in "Enable User Code by Area". Only Users 1-195 can
be assigned through addresses 5380-5574 in Direct Address Programming; other User
Areas must be assigned through the PCD-Windows software.
Press the R button to set the cursor to the User Code. Use the number buttons
1 through 9 to enter a code from 3 to 6 digits. Enter up to 6 digits in the first
six boxes from left to right for each user code. Valid entries are: 0-9. Note: Press the
0 button for a zero. No blank spaces in between; leave blank (•) any trailing boxes.
If an "Ambush Code" (Address 0990) is entered, do not program the first two digits of
ANY User Code as the same digits entered for the "Ambush Code".
If the programmed code is less than 6 digits, press the R button to set the cursor to
the OPTION/LEVEL.
Refer to the tables below for the available User Option and User Level data entries.
Enter the user options data in the left digit. Enter the level data (with arming options, if
any, added) in the right digit. Note: For entries greater than 9, press the
D1
buttons through the
D5 buttons for B through F, respectively.
For Keypad Output Control, press the R button once again to program applicable
keypads. Refer to the tables below, use the number buttons to enter the data for Keypad
1–4 in the right digit; and the data for Keypad 5–8 data in the left digit. (Press the
0
buttons for blank).
Press U to save each code.
To proceed to the next User Code, set the cursor to the User Number and change it using
the number buttons. Program a new User Code as previously described. Press NEXT
button to proceed.
USER OPTIONS
USER CODE
(UP TO 6 DIGITS)
USER
OPTION
USER
LEVEL
OUTPUT CONTROL
KEYPADS
DATA
ENTRIES
AUTHORITY
LEVEL
CODE
TYPE
blank (•) NONE ARM/DISARM
1 LEVEL 1 ARM/DISARM
2 LEVEL 2 ARM/DISARM
3 LEVEL 3 ARM/DISARM
4 NONE ARM ONLY
5 LEVEL 1 ARM ONLY
6 LEVEL 2 ARM ONLY
7 LEVEL 3 ARM ONLY
8 NONE SERVICE
9 LEVEL 1 SERVICE
0 LEVEL 2 SERVICE
B LEVEL 3 SERVICE
C* NONE AMBUSH
D* LEVEL 1 AMBUSH
E* LEVEL 2 AMBUSH
F* LEVEL 3 AMBUSH
Note: “Y” indicates option is enabled.
USER OPTIONS
DATA
ENTRIES
BLOCKED
VIEW
USER
PROGRAM
BYPASS OVERVIEW
blank (•)
1 Y
2 Y
3 Y Y
4 Y
5 Y Y
6 Y Y
7 Y Y Y
8 Y
9 Y Y
0 Y Y
B Y Y Y
C Y Y
D Y Y Y
E Y Y Y
F Y Y Y Y
DISABLED
Note: “Y” indicates option is
OUTPUT CONTROL KEYPADS
DATA
ENTRIES
K.P. 1 K.P. 2 K.P. 3 K.P. 4
blank (•)
1 Y
2 Y
3 Y Y
4 Y
5 Y Y
6 Y Y
7 Y Y Y
8 Y
9 Y Y
0 Y Y
B Y Y Y
C Y Y
D Y Y Y
E Y Y Y
F Y Y Y Y
NONE
Example: Enter a code of “123456” as
“123456” (from left to right).
Note: “Y” indicates option is enabled.
OUTPUT CONTROL KEYPADS
DATA
ENTRIES
K.P. 5 K.P. 6 K.P. 7 K.P. 8
blank (•)
1 Y
2 Y
3 Y Y
4 Y
5 Y Y
6 Y Y
7 Y Y Y
8 Y
9 Y Y
0 Y Y
B Y Y Y
C Y Y
D Y Y Y
E Y Y Y
F Y Y Y Y
NONE
*Note: These entries are only
available when address 7953
option 8 is enabled.
User# User Code
Enter user code
001 123 - 1-
(continued)
Note:
Change Burg User
Codes at a Burg keypad
in User Programming
with the appropriate au-
thority level;
Change Fire User Codes
at a Fire keypad (not
necessary to be keypad
#1) logged into User
programming with the
proper authority level.
To Next Page
