StarLink
™
SLE Commercial LTEVI & LTEAI Series Dual-Path Alarm Communicators -- Installation Instructions 13
Alternate Telco Line to Alarm Panel Supervision
The following wiring and programming method allows an existing FACP to use its two telephone connections
(primary and secondary) for supervision and central station reporting through the StarLink SLE-LTEVI-FIRE radio.
By removing the JP2 shunt and enabling the feature "Tip/Ring Wiring Fault Report", when any radio trouble is
detected, the StarLink radio will remove voltage from the secondary telephone output, triggering the FACP to
locally annunciate the Telco trouble and report the trouble to the central station.
NOTES
