WI1370 XP-400 Installation Instructions
Telephone Number 3 Programming
[50] - [59]
Programming is the same as for Telco 1.
Program to split/double report to Telco 3.
Refer to sections [30] through [39].
Report Codes
[60]Zone Report Codes
Report Code for Zones 1 through 4.
4/2 format - The Zone Report Code is the
1st digit of the report code sent, the second
digit is the zone number of the reporting
zone. For example, if zone 2 has a
reportcode of 3, the report code would be
32
.
3/1 format - Sends only the report Code
and does not append it with the zone
number.
[61]Point ID Report Codes
Point ID Report Codes are defaulted to
Burglary for zones 1 through 4. Optionally,
Point ID codes for zones 1 through 4 can be
programmed as follows:
[1] Reserved [7] Gas Alarm
[2] Panic [8] Heat Alarm
[3] Burglary [9] Reserved
[4] Holdup [A] Auxiliary
[5] General Alarm [B] 24 Hour
[6] Reserved
[62]Zone Codes
[62-1] Restore code - Zones 1 through 8.
The second digit of the restore code is the
zone number of the restored zone. For
example, if the Zone Restore Code [62] is
programmed to E, the restore code for that
zone would be E4 (4/2 format).
[62-2] Trouble Code - Conditional Closing
Reports. Zones that are bypassed at the
time of arming send this code along with the
zone number of the bypassed zone(s). For
example a conditional closing by User 2,
with zones 2 and 3 bypassed would be as
follows: 1234 C2
F2
F3
[63]System Report Codes
Program a 2-digit report code for Keypad
Panic 2, Keypad AUX, Keypad Panic, Test
Timer, AC Fail, Low Battery and Trouble.
[64]System Restore Code
The code sent when a system condition
restores. The second digit of the 2-digit
restore code is the second digit of the
System Report Code [63]. For example, if a
Low Battery System Report Code is F8 the
Battery Restore would be E8 (4/2 format).
[65]Opening and Closing Codes
Program Opening and Closing Codes for
Users 1 through 4. The second digit of the
report code is the number of the user that
armed or disarmed the system. For
example, if the Closing Code [65] is
programmed with a C, the closing code for
User 2 would be
C2
(4/2 format).
