diagram for electrical connectionS
Warranty
BIG44RB:
ELECTRODE
IGNITER
- 12VAC/DC, 1.5W, 120mA
FUSE
- 2 A
TRANSFORMER
- INPUT: 230v 50z
- OUTPUT: 12VAC ~ 2083mA, 25W
POWER
SWITCHES - KNOBS
CONTROL BOX
- OUTPUT: 12VDC, 24W
S
WIT
C
H - IGNITI
ON
- 12VDC
,
0.3~0.8W
,
22~66mA
S
WIT
C
H - LIGHT
S
-
12VDC
,
0.3~0.8W
,
22~66m
A
KNOB LIGHT
BIG44RB x8, BIG38RB x6, BIG32RB x5
- 12VDC, 0.3~8W, 34~95mA
YELL
O
W
R
ED
/
BLACK
B
LA
C
K
BIG32RB &BIG38RB:
GROUND
SWITCH - LIGHTS
- 12VDC, 0.3~0.8W, 22~66mA
BLACK
KNOB LIGHT
BIB10 x1
- 12VDC, 0.3~8W, 34~95mA
BLACK
RED /
ROUGE /
ROJO
BIG44RB, BIG38RB, BIG32RB
BIB10
