Andiron, see “ANDIRON
AND GRATE ASSEMBLY”
section.
Logs, see “LOG PLACE-
MENT” section.
Media, see “MEDIA” sec-
tion.
Rating Plate, see “RATING
PLATE INFORMATION”
section.
Batteries, see “BATTERY
INSTALLATION” section.
2
W415-1071 / C / 01.11.12
NOTE: Changes, other than editorial, are denoted by a vertical line in the margin.
TABLE OF CONTENTS
1.0 INSTALLATION OVERVIEW 2
2.0 INTRODUCTION 3
2.1 GENERAL INSTRUCTIONS 4
2.2 GENERAL INFORMATION 5
2.3 MINIMUM APPLIANCE SIZE 5
2.4 RATING PLATE 5
3.0 INSTALLATION 6
3.1 GAS PIPING 6
3.2 DAMPER STOP INSTALLATION 7
4.0 FINISHING 8
4.1 ANDIRON AND GRATE ASSEMBLY 8
4.2 BATTERY INSTALLATION 8
4.3 LOG PLACEMENT 9
4.4 MEDIA 10
4.5 LOGO PLACEMENT 10
4.6 OPTIONAL ROCK PLACEMENT 11
4.7 OPTIONAL REMOTE INSTALLATION (NOT SUPPLIED) 11
5.0 WIRING DIAGRAM 12
6.0 OPERATION 13
6.1 OPERATING AND LIGHTING INSTRUCTIONS 13
7.0 ADJUSTMENTS 14
7.1 PILOT BURNER ADJUSTMENT 14
7.2 VENTURI ADJUSTMENT 14
7.3 FLAME CHARACTERISTICS 15
8.0 MAINTENANCE 15
9.0 REPLACEMENTS 16
10.0 TROUBLE SHOOTING 18
11.0 WARRANTY 20
12.0 SERVICE HISTORY 21
1.0 INSTALLATION OVERVIEW
