W415-0702 / B / 04.04.12
43
11.0 REPLACEMENTS
Contact your dealer or the factory for questions concerning prices and policies on replacement parts. Normally
all parts can be ordered through your Authorized dealer / distributor.
FOR WARRANTY REPLACEMENT PARTS, A PHOTOCOPY OF THE ORIGINAL INVOICE WILL BE
REQUIRED TO HONOUR THE CLAIM.
When ordering replacement parts always give the following information:
• Model & Serial Number of appliance
• Installation date of appliance
• Part number
• Description of part
• Finish
* IDENTIFIES ITEMS WHICH ARE NOT ILLUSTRATED. FOR
FURTHER INFORMATION, CONTACT YOUR AUTHORIZED DEALER.
41.1
FAILURE TO POSITION THE PARTS
IN ACCORDANCE WITH THIS
MANUAL OR FAILURE TO USE ONLY
PARTS SPECIFICALLY APPROVED
WITH THIS APPLIANCE MAY
RESULT IN PROPERTY DAMAGE OR
PERSONAL INJURY.
!
WARNING
COMMON COMPONENTS
REF PART NO. DESCRIPTION
1 W660-0052 LOW LIMIT SWITCH 140°F (80°C)
2 W660-0055 HIGH LIMIT SWITCH 200°F (93°C)
3 W660-0056 VACUUM SWITCH
4* W195-0004 POWER CORD
5 NPAM AUGER MOTOR KIT
7 W062-0027 COMBUSTION BLOWER
8 W290-0111 COMBUSTION BLOWER MOUNTING GASKET
9 W290-0120 COMBUSTION BLOWER MOTOR MOUNTING GASKET
10 W290-0113 CONVECTION BLOWER GASKET
11* W255-0020 PRESSURE FITTING TAP
12 W570-0107 AUGER SCREW
13 W390-0002 DOOR LATCH
14 W555-0061 SCRAPER ROD
15 W105-0012 NYLON BUSHING
16 W500-0038 COTTER PIN
17* W750-0215 HARNESS WIRE
18* W385-0334 NAPOLEON® LOGO
19* W010-1528 CONTROL DOOR ASSEMBLY
20 W475-0555 BOTTOM OI PANEL
21 W720-0089 IGNITOR HOUSING
22 W390-0012 CONTROL PANEL LATCH
23* W010-1490 EXHAUST TUBE
24 W357-0007 IGNITOR
26 W350-0361 CONTROL HOUSING
27 W080-0932 MOTOR BRACKET
28 W010-1491 COMBUSTION AIR TUBE ASSEMBLY
29 W030-0022 ACCENT BAR (2)
30 W135-0320 CAST, BURN POT
31* W430-0002 MAGNETIC DOOR CATCH ASSEMBLY (2)
32* W290-0120 MOTOR MOUNTING GASKET
33 W290-0119 IGNITION GASKET
