Napoleon PRO285X Instructions

37
www.napoleongrills.com
N415-0437CE-GB-DE OCT 23.17
Parts List
Item Part # Descripon
35 Z570-0029 10-24 x 35mm screw x
36 N325-0082 top/boom handle x
37 N485-0023 clevis pin x
38 N485-0021 coer pin x
39 N080-0302 cross light bracket x
40 N305-0087-BK2FL le cooking grid x
41 N305-0088-BK2FL right cooking grid x
42 N735-0018 leg pivot washer x
43 N720-0067-SS1SG foot frame tube x
44 N272-0001 scissor cart foot x
45 N325-0084 scissor cart foot handle x
46 N160-0037 CE tank strap bracket x
47 N010-0806-SS1SG wheel side frame x
48 Z745-0001 wheel x
49 N015-0009 axle x
50 N160-0026 side shelf folding clip x
51 N450-0043 axle cap x
52 N655-0200 le top handle support x
53 N655-0201 right top handle support x
54 N390-0003 handle latch x
55 N685-0017 temperature gauge x
56 N135-0048-BK1HG lid casng x
57 W450-0027 1/2” brass nut x
58 N255-0057 3/8” - 1/4” union ng x
59 N255-0014 ng x
60 N640-0003 regulator strap x
61 N735-0019 8mm washer x
62 N570-0108 M8 x 35mm screw x
63 N570-0109 M8 x 60mm screw x
64 Z450-0015 M8 nut x
65 N485-0022 8 x 50mm clevis pin x
66 N570-0110 shoulder screw x
67 N720-0060 manifold ex x
68 N555-0058 lighng rod x
69 N390-0004-BK1SG slide lock latch x
70 N630-0006 spring x
71 N390-0005-SS1SG slide handle latch x
72 N500-0042B slide handle x
73 Z570-0023 10-24 x 6mm screw x
74 N010-0942 lid assembly x
75 N475-0319-SER control panel assembly x
76 N010-0943 top handle assembly x
77 N010-0820-SER side shelf assembly x
78 N325-0082B-SER boom handle assembly x
79 N325-0084-SER scissor cart foot handle assembly x
80 N525-0047-BK1SG-SER rail sliding track assembly x
