Figure 4. sbRIO-9628 Block Diagram
sbRIO-9628
Intel Atom E3825
Dual-Core
1.33 GHz Processor
UARTRS-232
UART
RS-232
UARTRS-485
High-Speed CAN
Xilinx Artix-7 100T
Real-Time
Clock
Battery Holder
(BR1632)
Temperature
Sensors
Watchdog
4 GB
eMMC Disk
1 GB
DDR3L
RS-232
RS-232
Console Out
RS-485
RJ-45 TSN Gigabit
Ethernet Port
RJ-45 TSN Gigabit
Ethernet Port
USB 2.0 Host
Type-A Connector
USB 2.0 Host
Type-A Connector
USB 2.0 Device
Type-C Connector
USB 3.1 Host
Type-C Connector
with DisplayPort
MicroSD
Connector
XCVR
XCVR
XCVR
PHY
PHY
CAN Port
Connector0 (MIO)
CAN
Controller
5 V
3.3 V
SATA 2.0
PCIe x1 Gen 2
USB 2.0
VBAT
LabVIEW FPGA API Data Path
Processor Data Path
NI-DAQmx API Data Path
Power Path
4x Digital I/O
(5 V Tolerant)
16x Multiplexed
Analog Input
4x Analog
Output
9-30 VDC
Input
Power
Selection and
Protection
On-board
Power
Supplies
Power
Connector
Configurable per Module
NI-DAQmx
Technology
Configurable per Module
NI-DAQmx
Technology
Optional System
Power 9-30 VDC
2x C Series
Module Interface
FPGA_VIO [0-47]
Digital I/O [0-47], SE/LVDS
Digital I/O [48-95], SE/LVDS
FPGA_VIO [48-95]
2.5 V/3.3 V
Power Selector
2.5 V/3.3 V
Power Selector
RMC Connector
(240-pin 60x4 Searay)
CompactRIO Single-Board Controller with NI-DAQmx Hardware Installation Manual | © National Instruments | 7
