Connecting a Three-Wire Current
Transducer
NI 9253
V
sup
COM
+
–
COM
V
sup
AI0
External
Power
Supply
Three-Wire
Current
Transducer
2 A
Max
OUT
+
–
NI 9253 Getting Started Guide | © National Instruments | 9
