National Instruments NI PXIe-4112 Getting Started Guide

GETTING STARTED GUIDE
NI PXIe-4112/4113
Dual-Output Programmable DC Power Supply
Note Before you begin, install and configure your chassis and controller.
This document explains how to install, configure, and test the NI PXIe-4112/4113
(NI 4112/4113). The NI 4112/4113 are single-quadrant, dual output, 60 W programmable DC
power supplies.
To access NI 4112/4113 documentation, navigate to Start»All Programs»National
Instruments»NI-DCPower»Documentation.
Contents
Electromagnetic Compatibility Guidelines...............................................................................1
Verifying the System Requirements..........................................................................................2
Unpacking the Kit..................................................................................................................... 2
Kit Contents...................................................................................................................... 3
Other Equipment............................................................................................................... 4
Preparing the Environment....................................................................................................... 4
Safety........................................................................................................................................ 5
Installing the Software.............................................................................................................. 5
Installing the NI 4112/4113.......................................................................................................5
Configuring the NI 4112/4113 in MAX....................................................................................8
Programming the NI 4112/4113................................................................................................9
Troubleshooting...................................................................................................................... 10
What Should I Do if the NI 4112/4113 Doesn't Appear in MAX?................................. 10
Where To Go Next.................................................................................................................. 11
Worldwide Support and Services............................................................................................ 11
Electromagnetic Compatibility Guidelines
This product was tested and complies with the regulatory requirements and limits for
electromagnetic compatibility (EMC) stated in the product specifications. These requirements
and limits are designed to provide reasonable protection against harmful interference when the
product is operated in the intended operational electromagnetic environment.
This product is intended for use in industrial locations. However, harmful interference may
occur in some installations, when the product is connected to a peripheral device or test object,
or if the product is used in residential or commercial areas. To minimize interference with
