7. Update the output calibration constants by configuring and calling the niDCPower Cal
Adjust Voltage Level VI or niDCPower_CalAdjustVoltageLevel function.
a) Input the DMM measurements as the measured outputs.
b) Input the test points as the requested outputs.
c) Input the specified level range as the range.
8. If more than one level range is specified, repeat the previous steps using the values
specified in each level range.
Related Information
For information about VIs or functions, refer to the programming reference of the NI DC
Power Supplies and SMUs Help.
Connecting and Configuring Equipment for Current
Adjustment
1. Make the necessary connections for this procedure, as shown in the following figure.
Figure 8. Current Verification or Adjustment Connection Diagram
NI-DCPower Device
Sense –
Sense +
+
–
DMM
Current
Mode
+
–
2. Set the niDCPower Output Function property or NIDCPOWER_OUTPUT_FUNCTION
attribute to DC Current for the NI 4112.
Adjusting Current Output and Measurement
Compare a set of currents measured by the external DMM to both a set of current test points
requested by the NI 4112 and to the measured currents reported by the NI 4112.
Refer to the following table as you complete the following steps.
NI PXIe-4112 Calibration Procedure | © National Instruments | 15
