Page #8 background image
Note For more information about installing slot blockers and filler
panels, go to ni.com/r/pxiblocker.
12. Power on the chassis.
Con󽘀guring the PXIe-446x in MAX
Use Measurement & Automation Explorer (MAX) to configure your NI hardware. MAX
informs other programs about which NI hardware products are in the system and
how they are configured. MAX is automatically installed with NI-DAQmx.
1.
Launch MAX.
2.
In the configuration tree, expand Devices and Interfaces to see the list of
installed NI hardware.
Installed modules appear under the name of their associated chassis.
3. Expand your Chassis tree item.
MAX lists all modules installed in the chassis. Your default names may vary.
Note If you do not see your module listed, press <F5> to refresh the
list of installed modules. If the module is still not listed, power o the
system, ensure the module is correctly installed, and restart.
4. Record the identifier MAX assigns to the hardware. Use this identifier when
programming the PXIe-446x.
5. Self-test the hardware by selecting the item in the configuration tree and
clicking Self-Test in the MAX toolbar.
The MAX self-test performs a basic verification of hardware resources.
PXIe-446x Pinout and LEDs
The following figures show the front panel connections of the PXIe-446x.
ni.com
8
PXIe-4466/4467/4468 Getting Started Guide
