Chapter 2 Basic Functions

Interface

CF20 LAN interface parameter * ‡

CF21 Command language parameter * B

CF22 Emulation parameter during remote control * B

CF23 SCPI communication error display parameter * A

CF24 Multichannel (VMCB) domain number parameter * ‡

B or C

CF25 Multichannel (VMCB) channel number * ‡

B or C

LAN

CF30 IP address display (1) * —

CF31 IP address display (2) * —

CF32 IP address display (3) * —

CF33 IP address display (4) * —

CF34 MAC address display (1) and (2) * —

CF35 MAC address display (3) and (4) * —

CF36 MAC address display (5) and (6) * —

CF40 Resets (LCI/DEF) or applies (APPL) the LAN settings. * A

CF41 IP address assignment method * ‡ B or C

CF42 Manual IP address setting (1) * ‡ B or C

CF43 Manual IP address setting (2) * ‡ B or C

CF44 Manual IP address setting (3) * ‡ B or C

CF45 Manual IP address setting (4) * ‡ B or C

CF46 IP address subnet mask prefix setting * ‡ B or C

CF47 SCPI-RAW protocol TCP port number * ‡ B or C

USB CF50 VID (vendor ID) display * —

CF51 PID (product ID) display * —

RS232C CF52 RS232C baud rate parameter * B

You can only specify this parameter when the RMX programmable power supply is being used as a master unit.

You can only specify this parameter only when the RMX programmable power supply is being used as a slave unit.

This parameter is affected only when the LAN interface settings are reset (CF40: dEF).

This parameter is displayed only when the LAN interface is in use (CF20: on).

Table 2-3. CONFIG Settings (Continued)
