20 ALGO® 5 Newborn Hearing Screener Service Manual
P/N 000976 Rev.A
The following figure gives an overview of the hardware components tested during the series of
Equipment Check tests.
FIGURE 13: Equipment Check - Overview
The following lists each step in the Equipment Check and identifies which device is
involved in the testing:
• DSP Box Test – DSP Box and Panel PC
• Cable Connections – ATA 5 and Preamp 5
• Calibration Date – ATA 5
• Artifact Test – DSP Box and Preamp 5
• Acoustic Test – ATA 5
• Impedance Test – PCA 5
2.4.2. Component tests
2.4.2.1. General
The Service Menu allows performing the following tests in non-screening mode:
• Print a test page on Page printer
• Print a test page on Label printer
• Scan a Bar code and view result
DSP Box
Preamp 5
ATA 5 Cable
PCA 5 Cable
Equipment
Check Kit
