3.3. Troubleshooting the Isolation Transformer
Follow the steps below to change the Isolation Transformer’s fuse:
• Unplug the power cable leading from the Isolation Transformer to the wall.
• Locate the power inlet module on the Isolation Transformer. Note the orientation of
the power inlet module so as to put it back in the same direction.
• Using a flat head screwdriver, open the power inlet module to access the fuse holder
(refer to FIGURE 21: Open the power inlet module ).
FIGURE 21: Open the power inlet module
• Using a flat head screwdriver, remove the fuse holder from the drawer (refer to
FIGURE 22)
FIGURE 22: Access to the fuse holder
