ALGO® 5 Newborn Hearing Screener Service Manual
P/N 000976 Rev.A
7
• Preamplifier 5 (Preamp 5) - (amplifies signals from the electrodes, also serves
as isolation for the patient)
• DSP Box (processes digital signals from Preamp 5)
• Label printer
• Page printer (optional, available in inkjet or laser models)
• Bar code scanner (optional)
• LAN Isolator (optional)
1.3. Pictorial introduction to the ALGO 5
This section is meant to acquaint you with various views of the ALGO 5 that you will see
in the course of troubleshooting and repairing it. The item names used in the Parts List
(see Chapter 5) are used throughout the manual whenever parts are discussed.
FIGURE 1: ALGO 5 — front view
DSP Box
Drawer for Disposables
Cart Column with Integrated
Cable Management
Isolation Transformer
Keyboard
Label Printer
Shelf Space
Page Printer
(optional)
Panel PC
