NV10/NV7.5 Operations and Maintenance Manual Operating the transmitter
Issue 3.4 2016-08-03 Page 2-45
Viewing real-time meters
The AUI can be used to display metered parameters on the Home page (see Figure 2.30), if
selected individually from the
Meters List View page or saved in a meter list layout and set to
default.
This section includes the following topics:
• Describing the meter display on page 2-46
• Accessing meter information on page 2-47
• Identifying meter information on a specific sub-device on page 2-48
• Saving a meter list on page 2-49
Figure 2.30: Meters Page
HOME PAGE
Information
Selected
Meters
Buttons
View
Save
Arrow
To Next Page
