29
Keep the ywheel stable during this procedure. Do not turn
the crank arms. Flywheel movement can pull ngers in and
cause injury.
2. Using a #2 Phillips screwdriver, loosen and remove the hardware that
attaches the Fender to the Main Frame. Set the hardware safely aside for
reassembly.
NOTICE: Hold the Fender so that it does not fall.
3. Loosen the Resistance Knob to the minimum resistance setting.
4. Using a small (2-3mm) steel pin and hammer, push the Roll Pin out
of the Collar and Resistance Adjustment Shaft. You may need to push
down slightly on the Resistance Knob at the same time.
5. Turn the Resistance Knob in the direction to increase resistance
until the tip of the threaded Resistance Adjustment Shaft comes out of the
Resistance Nut.
Note: Your machine may not match the images provided exactly.
1. Unplug the AC Adapter from the wall outlet and machine.
Fender
Resistance Knob
Resistance Adjust-
ment Shaft
Collar
Roll Pin
Resistance Nut
To Next Page
